4.8.6 7-3* Process PID Ctrl.

Parameter 7-30 Process PID Normal/ Inverse Control
Table 385: Parameter 7-30 Process PID Normal/ Inverse Control
7-30 Process PID Normal/ Inverse Control
Default value: [0] Normal
Conversion index: –
Normal and inverse controls are implemented by introducing a difference between the reference signal and the feedback signal.
Option Name
[0]* Normal
[1] Inverse
Parameter 7-31 Process PID Anti Windup
Table 386: Parameter 7-31 Process PID Anti Windup
7-31 Process PID Anti Windup
Default value: [1] On
Conversion index: –
Normal and inverse controls are implemented by introducing a difference between the reference signal and the feedback signal.
Option Name Description
[0] Off Continue regulation of an error even when the output frequency cannot be increased or decreased.
[1]* On Cease regulation of an error when the output frequency can no longer be adjusted.
