VLT® AutomationDrive EZ FC 321
Programming Guide
Parameter
Parameter 13-40 Logic Rule Boolean 1 [0]
Parameter 13-42 Logic Rule Boolean 2 [0]
Parameter 13-41 Logic Rule Operator 1 [0]
Parameter 13-40 Logic Rule Boolean 1 [1]
Parameter 13-42 Logic Rule Boolean 2 [1]
Parameter 13-41 Logic Rule Operator 1 [1]
Parameter 13-15 RS-FF Operand S [0]
Parameter 13-16 RS-FF Operand R [0]
Parameter 13-51 SL Controller 1 Event [0]
Parameter 13-52 SL Controller 1 Action [0]
Parameter 13-51 SL Controller 1 Event [1]
Parameter 13-52 SL Controller 1 Action [1]
Parameter 13-15 RS-FF Operand S
Table 459: Parameter 13-15 RS-FF Operand S
13-15 RS-FF Operand S
Default Value: Size related
Conversion Index: -
Option Name
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
Danfoss A/S © 2021.08
Setting
[37] Digital input DI32
[2] Running
[3] AND NOT
[37] Digital input DI32
[2] Running
[1] AND
[26] Logic rule 0
[27] Logic rule 1
[94] RS Flipflop 0
[22] Run
[27] Logic rule 1
[24] Stop
Parameter Type: Option, Array [10]
Data Type: Uint8
Description
Notes
–
–
–
–
–
–
Output from parameter 13-41 Log ic Rule Operator 1 [0].
Output from parameter 13-41 Log ic Rule Operator 1 [1].
Output from parameter 13-15 RSFF Operand S and parameter
13-16 RSFF Operand R.
–
–
–
Setup: 2 set-ups
Change during operation: True
AU373327181955en-000101 / 130R1208 | 241
