VLT® AutomationDrive EZ FC 321
Programming Guide
Option Name
[0] DISABLED
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND NOT
[8] NOT OR NOT
Parameter 13-42: Logic Rule Boolean 2
Table 464: Parameter 13-42 Logic Rule Boolean 2
13-42 Logic Rule Boolean 2
Default Value: Size related
Conversion Index: -
Option Name
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
250 | Danfoss A/S © 2021.08
Description
Ignores
• Parameter 13-42 Logic Rule Boolean 2.
• Parameter 13-43 Logic Rule Operator 2.
•
Parameter 13-44 Logic Rule Boolean 3.
Evaluates the expression [13-40] AND [13-42].
Evaluates the expression [13-40] OR [13-42].
Evaluates the expression [13-40] AND NOT [13-42].
Evaluates the expression [13-40] OR NOT [13-42].
Evaluates the expression NOT [13-40] AND [13-42].
Evaluates the expression NOT [13-40] OR [13-42].
Evaluates the expression NOT [13-40] AND NOT [13-42].
Evaluates the expression NOT [13-40] OR NOT [13-42].
Parameter Type: Option, Array [4]
Data Type: Uint8
Description
nd
Select the 2 boolean (true or false) input for the selected logic rule. See parameter 13-01 Start
Event and parameter 13-02 Stop Event for more information.
Parameter Descriptions
Setup: 2 set-ups
Change during operation: True
