VLT® AutomationDrive EZ FC 321
Programming Guide
Parameter 8-58 PROFIdrive OFF3 Select
Table 446: Parameter 8-58 PROFIdrive OFF3 Select
8-58 PROFIdrive OFF3 Select
Default value: [3] Logic OR
Conversion index: –
Select control of the drive OFF3 selection via the terminals (digital input) and/or via the fieldbus. This parameter is active only when
parameter 8-01 Control Site is set to [0] Digital and ctrl. word and parameter 8-10 Control Word Profile is set to [1] PROFIdrive profile.
Option
[0]
[1]
[2]
[3]*

4.9.6 8-8* FC Port Diagnostics

These parameters are used for monitoring the bus communication via the drive RS485 port terminals 68–69.
Parameter 8-80 Bus Message Count
Table 447: Parameter 8-80 Bus Message Count
8-80 Bus Message Count
Default value: 0
Conversion index: 0
This parameter shows the number of valid telegrams detected on the bus.
Parameter 8-81 Bus Error Count
Table 448: Parameter 8-81 Bus Error Count
8-81 Bus Error Count
Default value: 0
Conversion index: 0
This parameter shows the number of telegrams with faults (for example, CRC fault) detected on the bus.
Parameter 8-82 Slave Messages Rcvd
Table 449: Parameter 8-82 Slave Messages Rcvd
8-82 Slave Messages Rcvd
Default value: 0
Conversion index: 0
This parameter shows the number of valid telegrams addressed to the slave sent by the drive.
Danfoss A/S © 2021.08
Parameter type: Option
Data type: Uint8
Name
Digital input
Bus
Logic AND
Logic OR
Parameter type: Range, 0 - 0
Data type: Uint32
Parameter type: Range, 0 - 0
Data type: Uint32
Parameter type: Range, 0 - 0
Data type: Uint32
Parameter Descriptions
Setup: All setups
Change during operation: True
Description
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
AU373327181955en-000101 / 130R1208 | 227
