4.9.5 8-5* Digital/Bus

Parameters for configuring the control word merging.
These parameters are only active when parameter 8-01 Control Site is set to [0] Digital and control word.
Parameter 8-50 Coasting Select
Table 438: Parameter 8-50 Coasting Select
8-50 Coasting Select
Default value: [3] Logic OR
Conversion index: –
Select the trigger for the coasting function.
Option Name
[0] Digital input
[1] Bus
[2] Logic AND
[3]* Logic OR
Parameter 8-51 Quick Stop Select
Table 439: Parameter 8-51 Quick Stop Select
8-51 Quick Stop Select
Default value: [3] Logic OR
Conversion index: –
Select the trigger for the quick stop function.
Option Name
[0] Digital input
[1] Bus
[2] Logic AND
[3]* Logic OR
Parameter 8-52 DC Brake Select
Table 440: Parameter 8-52 DC Brake Select
8-52 DC Brake Select
Default value: Size related
Conversion index: –
Select control of the DC brake via the terminals (digital input) and/or via the fieldbus.
224 | Danfoss A/S © 2021.08
N O T I C E
Parameter type: Option
Data type: Uint8
Description
A digital input triggers the coasting function.
A serial communication port or the fieldbus triggers the coasting function.
The fieldbus/serial communication port and a digital input trigger the coasting function.
The fieldbus/serial communication port or a digital input triggers the coasting function.
Parameter type: Option
Data type: Uint8
Description
A digital input triggers the quick stop function.
A serial communication port or the fieldbus triggers the quick stop function.
The fieldbus/serial communication port and a digital input trigger the quick stop function.
The fieldbus/serial communication port or a digital input triggers the quick stop function.
Parameter type: Option
Data type: Uint8
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
