VLT® AutomationDrive EZ FC 321
Programming Guide
Option Name
[2] PM, salient IPM
[5] SynRM
[6] PMaSynRM
Parameter 1-11 Motor Model
Table 71: Parameter 1-11 Motor Model
1-11 Motor Model
Default value: Size related
Conversion index: –
Automatically sets the factory values for the selected motor. If the default value [1] Std. Asynchron is used, determine settings man-
ually according to the selection in parameter 1-10 Motor Construction.
Option Name
[1] Std. asynchron
[2] Std. PM, non sali-
ent
[3] Std. PM salient
[10] Danfoss OGD
LA10
[11] Danfoss OGD
V210
Parameter 1-14 Damping Gain
Table 72: Parameter 1-14 Damping Gain
1-14 Damping Gain
Default value: 140%
Conversion index: 0
The damping gain stabilizes the PM machine to run smoothly and with stability. The value of damping gain controls the dynamic
performance of the PM machine. High damping gain gives high dynamic performance and low damping gain gives low dynamic
performance. The dynamic performance is related to the machine data and load type. If the damping gain is too high or low, the
control becomes unstable.
Parameter 1-15 Low Speed Filter Time Const.
Table 73: Parameter 1-15 Low Speed Filter Time Const.
1-15 Low Speed Filter Time Const.
Default value: Size related
Conversion index: -2
The time constant is used below 10% rated speed. Obtain quick control through a short dampening time constant. However, if this
value is too short, the control becomes unstable.
Danfoss A/S © 2021.08
Description
Use for IPM motors, interior-mounted magnet. PM motors are divided into 2 groups, with either
surface-mounted (SPM)/non-salient magnets or interior-mounted (IPM)/ salient magnets.
Use for SynRM, synchronous reluctance motors.
Use for PMaSynRM, Permanent Magnet assisted synchronous reluctance motors.
Parameter type: Option
Data type: Uint8
Description
Default motor model when [0] Asynchron is selected in parameter 1-10 Motor Construction.
Selectable when [1] PM, non-salient SPM is selected in parameter 1-10 Motor Construction.
Selectable when [1] PM, non-salient SPM is selected in parameter 1-10 Motor Construction. Only
available for T5 in 1.5–3 kW. Settings are loaded automatically for this specific motor.
Selectable when [1] PM, non-salient SPM is selected in parameter 1-10 Motor Construction. Only
available for T5 in 0.75–3 kW. Settings are loaded automatically for this specific motor.
Parameter type: Range, 0 - 250%
Data type: Int16
Parameter type: Range, 0.01 - 20 s
Data type: Uint16
Parameter Descriptions
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
AU373327181955en-000101 / 130R1208 | 65
