Parameter 5-65 Pulse Output Max Freq #29
Table 331: Parameter 5-65 Pulse Output Max Freq #29
5-65 Pulse Output Max Freq #29
Default value: Size related
Conversion index: 0
Set the maximum frequency for terminal 29 corresponding to the output variable selected in parameter 5-63 Terminal 29 Pulse Out-
put Variable.
4.6.7 5-7* 24 V Encoder Input
Connect the 24 V encoder to terminal 12 (24 V DC supply), terminal 32 (channel A), terminal 33 (channel B), and terminal 20 (GND).
The digital inputs 32/33 are active for encoder inputs when [1] 24 V encoder is selected in parameter 1-02 Flux Motor Feedback Source
and parameter 7-00 Speed PID Feedback Source. The encoder used is a dual-channel (A and B) 24 V type. Maximum input frequency:
110 kHz.
Encoder connection to the drive
24 V incremental encoder. Maximum cable length is 5 m (16.4 ft).
Danfoss A/S © 2021.08
Description
Parameter type: Range, 0 - 32000 Hz
Data type: Uint32
Parameter Descriptions
Setup: All setups
Change during operation: True
