VLT® AutomationDrive EZ FC 321
Programming Guide
Parameter 7-10 Torque PI Feedback Source
Table 377: Parameter 7-10 Torque PID Feedback Source
7-10 Torque PID Feedback Source
Default value: [0] Controller off
Conversion index: –
Select the feedback source for the torque controller.
Option Name
[0]* Controller off
[1] Analog input 53
[2] Analog input 54
[3] Estimated torque
Parameter 7-12 Torque PI Proportional Gain
Table 378: Parameter 7-12 Torque PI Proportional Gain
7-12 Torque PI Proportional Gain
Default value: 100%
Conversion index: 0
Enter the proportional gain value for the torque controller. Selection of a high value makes the controller react faster. Too high a
setting leads to controller instability.
Parameter 7-13 Torque PI Integration Time
Table 379: Parameter 7-13 Torque PI Integration Time
7-13 Torque PI Integration Time
Default value: 0.020 s
Conversion index: -3
Enter the integration time for the torque controller. Selection of a low value makes the controller react faster. Too low a setting
leads to controller instability.
Parameter 7-16 Torque PI Lowpass Filter Time
Table 380: Parameter 7-16 Torque PI Lowpass Filter Time
7-16 Torque PI Lowpass Filter Time
Default value: 5 ms
Conversion index: -4
Enter the time constant for the torque control low-pass filter.
Parameter 7-18 Torque PI Feed Forward Factor
Table 381: Parameter 7-18 Torque PI Feed Forward Factor
7-18 Torque PI Feed Forward Factor
Default value: 0%
Conversion index: 0
Danfoss A/S © 2021.08
Parameter type: Option
Data type: Uint8
Description
Select to operate in open loop.
Select to use torque feedback from the analog input.
Select to use torque feedback from the analog input.
Select to use the torque feedback estimated by the drive.
Parameter type: Range, 0 - 500%
Data type: Uint16
Parameter type: Range, 0.002 - 2 s
Data type: Uint16
Parameter type: Range, 0.1 - 100 s
Data type: Uint16
Parameter type: Range, 0 - 100%
Data type: Uint16
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
AU373327181955en-000101 / 130R1208 | 195
