Number Description
215 Start fwd/rev
216 Touch timeout
220 Configuration File Version not suppor-
ted
246 Power card supply
250 New spare part
251 New type code
430 PWM disabled
Cannot be auto reset via parameter 14-20 Reset Mode.
1
(X) Dependent on parameter.
A trip is the action following an alarm. The trip coasts the motor and is reset by pressing [Reset] or by a digital input (parameter
group 5-1* Digital Inputs). The original event that caused an alarm cannot damage the drive or cause dangerous conditions.
A trip lock is an action when an alarm occurs, which could damage the drive or connected parts. A trip lock situation can only be
reset by cycling power.

5.1.3 Indicator Light

Table 755: Indicator Light
Warning
Alarm
Trip locked

5.1.4 Alarm Word, Warning Word, and Extended Status Word

Table 756: Description of Alarm Word, Warning Word, and Extended Status Word
Bit Hex Dec
Alarm Word Extended Status Word
0 00000001 1
1 00000002 2
2 00000004 4
3 00000008 8
Danfoss A/S © 2021.08
Warning
X
–
X
–
–
–
–
Yellow
Flashing red
Yellow and red
Alarm word Alarm word
2
Brake check Servicetrip,
(A28) read/ write
Pwr.card temp Servicetrip,
(A69) (reserved)
Earth fault Servicetrip,
(A14) typecode/
spare part
Ctrl.card temp Servicetrip,
(A65) (reserved)
Alarm/trip Alarm/trip
lock
X –
X –
– –
– X
– X
X X
X –
Warning word Warning
word 2
Brake check Start de-
(W28) layed
Pwr.card temp Stop de-
(A69) layed
Earth fault Reserved
(W14)
Ctrl.card temp Reserved
(W65)
AU373327181955en-000101 / 130R1208 | 353
Troubleshooting
Parameter reference
Parameter 4-74 Start Fwd/Rev Func-
tion
Parameter 4-75 Touch Timout
–
–
–
–
–
Extended status word
Ramping
AMA running
Start CW/CCW
start_possible is active, when
the DI selections [12] OR [13]
are active and the requested
direction matches the refer-
ence sign
Slow down
