VLT® AutomationDrive EZ FC 321
Programming Guide
Parameter 0-32 Max Value of User-defined Readout
Table 25: Parameter 0-32 Max Value of User-defined Readout
0-32 Max Value of User-defined Readout
Default value: 100 CustomReadoutUnit
Conversion index: -2
This parameter sets the maximum value to be shown when the speed of the motor has reached the set value for parameter 4-13
Motor Speed High Limit [RPM] or parameter 4-14 Motor Speed High Limit [Hz] (depends on setting in parameter 0-02 Motor Speed Unit).
Parameter 0-33 Source for User-defined Redaout
Table 26: Parameter 0-33 Source of User-defined Readout
0-33 Source of User-defined Readout
Default value: [240] Default Source
Conversion index: –
Enter the source of the user-defined readout.
Option Name
[105] Torque relate to rated
[143] PID Clamped Output 4–20mA
[240]* Default Source
Parameter 0-37 Display Text 1
Table 27: Parameter 0-37 Display Text 1
0-37 Display Text 1
Default value: 0
Conversion index: 0
Enter a text which can be viewed in the graphical display by selecting [37] Display Text 1 in
•
Parameter 0-20 Display Line 1 Small
•
Parameter 0-21 Display Line 1.2 Small
• Parameter 0-22 Display Line 1.3 Small
•
Parameter 0-23 Display Line 2 Large
•
Parameter 0-24 Display Line 3 Large
Parameter 0-38 Display Text 2
Table 28: Parameter 0-38 Display Text 2
0-38 Display Text 2
Default value: 0
Conversion index: 0
Enter a text which can be viewed in the graphical display by selecting [38] Display Text 2 in
•
Parameter 0-20 Display Line 1 Small
•
Parameter 0-21 Display Line 1.2 Small
Danfoss A/S © 2021.08
Parameter type: Range [par. 0-31 -999999.99 Custom-
ReadoutUnit]
Data type: Int32
Parameter type: Option
Data type: Uint8
Parameter type: Range [0–25]
Data type: VisStr[25]
Parameter type: Range [0–25]
Data type: VisStr[25]
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Description
Setup: 1 setup
Change during operation: True
Setup: 1 setup
Change during operation: True
AU373327181955en-000101 / 130R1208 | 47
