4.4.2 3-1* References

Select the preset references. Select Preset ref. bit 0/1/2 [16], [17], or [18] for the corresponding digital inputs in parameter group 5-1*
Digital Inputs.
Parameter 3-10 Preset Reference
Table 178: Parameter 3-10 Preset Reference
3-10 Preset Reference
Default value: 0%
Conversion index: -2
Enter up to 8 different preset references (0–7) in this parameter, using array programming. The preset reference is stated as a per-
centage of the value Ref (parameter 3-03 Maximum Reference). If a Ref
MAX
programmed, the preset reference is calculated as a percentage of the full reference range, that is on the basis of the difference
between Ref and Ref . Afterwards, the value is added to Ref
MAX MIN
[16], [17] or [18] for the corresponding digital inputs in parameter group 5-1* Digital Inputs.
