VLT® AutomationDrive EZ FC 321
Programming Guide
Option Name
[1608] Position Error
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor Current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Motor Thermal
[1619] Thermistor Sensor Temperature
[1620] Motor Angle
[1621] Torque [%] High Res.
[1622] Torque [%]
[1623] Motor Shaft Power [kW]
[1624] Calibrated Stator Resistance
[1625] Torque [Nm] High
[1628] Angle Error
[1630] DC Link Voltage
[1631] System Temp.
[1632] Brake Energy /s
[1633] Brake Energy Average
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1636] Inv. Nom. Current
[1637] Inv. Max. Current
[1638] SL Controller State
[1639] Control Card Temp.
[1642] Service Log Counter
[1643] Timed Actions Status
Danfoss A/S © 2021.08
Description
Actual position PI error in position units selected in parameter 17-70 Position Unit.
Actual power consumed by the motor in kW.
Actual power consumed by the motor in hp.
Voltage supplied to the motor.
Motor frequency, that is, the output frequency from the drive in Hz.
Phase curent of the motor measured as effective value.
Motor frequency, that is, the output frequency from the drive in percent.
Actual motor torque in Nm.
Speed in RPM (revolutions per minute), that is, the motor shaft speed in closed loop.
Thermal load on the motor calculated by the ETR function.
Present motor load as a percentage of the rated motor torque.
DC-link voltage in the drive.
Present brake power transferred to an external brake resistor. Stated as an instant
value.
Brake power transferred to an external brake resistor. The mean power is calculated
continuously for the most recent 120 s.
Present heat sink temperature of the drive. The cutout limit is 95 ±5 °C (203 ±9 °F);
cutting back in occurs at 70 ±5 °C (158 ±9 °F).
Percentage load of the inverters.
Nominal current of the drive.
Maximum current of the drive.
State of the event executed by the control.
Temperature of the control card.
Parameter Descriptions
