VLT® AutomationDrive EZ FC 321
Programming Guide
Option Name
[0]* Log always
[1] Log once on trigger
Parameter 15-14 Samples Before Trigger
Table 533: Parameter 15-14 Samples Before Trigger
15-14 Samples Before Trigger
Default Value: 50
Conversion Index: 0
Before a trigger event, enter the percentage of all samples which should be retained in the log. See also parameter 15-12 Trigger
Event and parameter 15-13 Logging Mode.
Parameter 15-15 Info Message: "Service Log Full"
Table 534: Parameter 15-15 Info Message: "Service Log Full"
15-15 Info Message: "Service Log Full"
Default Value: [0] Disabled
Conversion Index: -
See Service log. By enabling this parameter, a text message is shown in the drive when the service log runs full: Clear logs, Service log
full: 28 [M26]. The message recommends to clear the log.
Option
[0]*
[1]

4.15.3 Service Log

The service log function saves detailed log information of a 5-second interval when alarms occur. Service technicians can analyze
this information to troubleshoot and optimize the drive.
The drive can save up to 24 service log records in the flash memory.
Find the list of alarms that trigger a service log record in
trips/alarms, for example, Safe Torque Off, do not trigger a service log record.
Sampling rate
There are 2 periods with different sampling rates:
• Slow samples: 20 samples at a rate of 250 ms resulting in 5 s of history before the trip.
• Fast samples: 50 samples at a rate of 5 ms resulting in 250 ms of detailed history before the trip.
To enable the real-time clock (RTC) stamp, use the real-time clock module. If real-time clock is not available, the operating time in
parameter 15-32 Fault Log: Time is recorded.
Table 535: Service Log Data
# Alarm log data
1 Time of trip (1 of the values):
290 | Danfoss A/S © 2021.08
Description
Select [0] Log always for continuous logging.
Select [1] Log once on trigger to start and stop logging conditionally using parameter 15-12 Trig-
ger Event and parameter 15-14 Samples Before Trigger.
Parameter Type: Range, 0 - 100
Data Type: Uint8
Parameter Type: Option
Data Type: Uint8
Name
Disabled
Enabled
4.15.7 Alarms that Trigger a Service Log
N O T I C E
Parameter
Parameter 0-89 Date and Time Readout or parameter 15-32 Fault Log:
Time
Setup: 2 set-ups
Change during operation: True
Setup: 1 set-up
Change during operation: True
Description
Enable message,
Record. Application-dependent
AU373327181955en-000101 / 130R1208
Parameter Descriptions
