LCP keys Description
Press [Status] for selecting the mode of display or for changing back to display mode from either the quick menu
mode, the main menu mode, or the alarm mode. Also use [Status] to toggle single or double readout mode.
[Quick Allows quick access to different quick menus such as:
Menu]
• My personal menu
• Quick set-up
• Changes made
• Loggings
Press [Quick Menu] to program the parameters belonging to the Quick Menu. It is possible to switch directly be-
tween quick menu mode and main menu mode.
[Main Is used for programming all parameters. It is possible to switch directly between main menu mode and quick menu
Menu] mode. Parameter shortcut can be carried out by pressing down [Main Menu] for 3 s. The parameter shortcut allows
direct access to any parameter.
[Alarm Shows an alarm list of the 5 latest alarms (numbered A1– A5). To obtain extra details about an alarm, press the
Log] navigation keys to maneuver to the alarm number and press [OK]. Information about the condition of the drive
before it enters the alarm mode is shown.
[Back] Returns to the previous step or layer in the navigation structure.
[Cancel] Last change or command is canceled as long as the display has not been changed.
[Info] Supplies information about a command, parameter, or function in any display window. [Info] provides detailed in-
formation whenever help is needed. Exit Info mode by pressing either [Info], [Back], or [Cancel].
Naviga- The 4 navigation keys are used to navigate between the different options available in Quick Menu, Main Menu, and
tion keys Alarm Log. Press the keys to move the cursor.
[OK] Press to select a parameter marked by the cursor and to enable the change of a parameter.
Local control keys: Local control keys are at the bottom of the control panel.
Table 5: Local Control Keys and Description
LCP Description
keys
[Hand Enables control of the drive via the LCP.
On]
[Hand On] also starts the motor, and it is now possible to enter the motor speed data with the navigation keys. The
key can be selected as [1] Enable or [0] Disable via parameter 0-40 [Hand on] Key on LCP.
External stop signals activated with control signals or a fieldbus override a start command via the LCP.
The following control signals are still active when [Hand On] is activated:
• [Hand on] - [Off] - [Auto On]
• Reset
• Coast stop inverse
• Reversing
• Set-up select bit 0 - Set-up select bit 1
• Stop command from serial communication
• Quick stop
• DC brake
[Off]
Stops the connected motor. The key can be selected as [1] Enable or [0] Disable via parameter 0-41 [Off] Key on LCP.
