Table 314: Local Reference Active
Reference site set in parameter 3-1 3 Reference Site
Reference site: Local parameter 3-13 Reference Site [2] Local
Reference site: Remote parameter 3-13 Reference Site [1] Remote
Reference site: Linked to Hand/ Auto
Hand
Hand⇒off
Auto⇒off
Auto
Option Name
[121] Remote ref active
[122] No alarm
[123] Start command active
[124] Running reverse
[125] Drive in hand mode
[126] Drive in auto mode
[180] Clock fault
[181] Prev. Maintenance
[188] AHF Capacitor Connect
[189] External Fan Control
[190] Safe Function active
[191] Safe Opt. Reset req.
[192] RS Flipflop 0
[193] RS Flipflop 1
[194] RS Flipflop 2
[195] RS Flipflop 3
[196] RS Flipflop 4
[197] RS Flipflop 5
[198] RS Flipflop 6
[199] RS Flipflop 7
168 | Danfoss A/S © 2021.08
Description
Output is high when parameter 3-13 Reference Site = [1] Remote or [0] Linked to hand/auto
while the LCP.
Output is high when no alarm is present.
Output is high when the start command is high (that is via digital input, bus connection,
[Hand On], or [Auto On]), and a stop has been the last command.
Output is high when the drive is running counterclockwise (the logical product of the status
bits running AND reverse).
Output is high when the drive is in hand-on mode (as indicated by the LED light above [Hand
On]).
Output is high when the drive is in auto-on mode (as indicated by LED on above [Auto On]).
The internal logics for the internal fan control is transferred to this output to make it possible
to control an external fan (relevant for hp duct cooling).
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
Local reference active [120]
1
0
1
1
0
0
Parameter Descriptions
Remote reference active [121]
0
1
0
0
0
1
AU373327181955en-000101 / 130R1208
