• Alarm word
• Status word
• Control word
• Extended status word
Events are logged with value and time stamp in ms. The time interval between 2 events depends on how often events occur (maxi-
mum once every scan time). Data logging is continuous, but if an alarm occurs, the log is saved and the values can be viewed on the
display. This feature is useful, for example when carrying out service following a trip. View the historic log contained in this parame-
ter via the serial communication port or via the display.
Parameter 15-20 Historic Log: Event
Table 537: Parameter 15-20 Historic Log: Event
15-20 Historic Log: Event
Default Value: 0
Conversion Index: 0
View the event type of the logged events.
Parameter 15-21 Historic Log: Value
Table 538: Parameter 15-21 Historic Log: Value
15-21 Historic Log: Value
Default Value: 0
Conversion Index: 0
View the value of the logged event. Interpret the event values as below:
Digital input
Digital output (not
monitored in this SW re-
lease)
Warning word
Alarm word
Status word
Control word
Extended status word
Parameter 15-22 Historic Log: Time
Table 539: Parameter 15-22 Historic log: Time
15-22 Historic log: Time
Default Value: 0 ms Parameter Type: Range, 0 - 2147483647 ms, Array [50]
Conversion Index: -3 Data Type: Uint32
View the time at which the logged event occurred. Time is measured in ms since the drive was started. The maximum value corre-
sponds to approximately 24 days, which means that the count restarts at 0 after this period.

4.15.9 15-3* Alarm Log

Parameters in this group are array parameters where up to 10 fault logs can be viewed. 0 is the most recent logged data and 9 is the
oldest. Fault codes, values, and time stamp can be viewed for all logged data.
294 | Danfoss A/S © 2021.08
Parameter Type: Range, 0 - 255, Array [50]
Data Type: Uint8
Parameter Type: Range, 0 - 2147483647, Array [50]
Data Type: Uint32
Decimal value. See parameter 16-60 Digital Input for a description after converting to binary value.
Decimal value. See parameter 16-66 Digital Output [bin] for a description after converting to binary val-
ue.
Decimal value. See parameter 16-92 Warning Word for a description.
Decimal value. See parameter 16-90 Alarm Word for a description.
Decimal value. See parameter 16-03 Status Word for a description after converting to binary value.
Decimal value. See parameter 16-00 Control Word for a description.
Decimal value. See parameter 16-94 Ext. Status Word for a description.
Parameter Descriptions
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
AU373327181955en-000101 / 130R1208
