VLT® AutomationDrive EZ FC 321
Programming Guide
Parameter 16-20 Motor Angle
Table 593: Parameter 16-20 Motor Angle
16-20 Motor Angle
Default Value: 0
Conversion Index: 0
View the current encoder/resolver angle offset relative to the index position. The value range of 0–65535 corresponds to 0–2xpi
(radian).
Parameter 16-21 Torque [%] High Res.
Table 594: Parameter 16-21 Torque [%] High Res.
16-21 Torque [%] High Res.
Default Value: 0%
Conversion Index: -1
The value shown is the torque in percent of nominal torque, with sign and 0.1% resolution, applied to the motor shaft.
Parameter 16-22 Torque [%]
Table 595: Parameter 16-22 Torque [%]
16-22 Torque [%]
Default Value: 0%
Conversion Index: 1
The value shown is the torque in percent of nominal torque, with sign, applied to the motor shaft.
Parameter 16-23 Motor Shaft Power [kW]
Table 596: Parameter 16-23 Motor Shaft Power [kW]
16-23 Motor Shaft Power [kW]
Default Value: 0 kW
Conversion Index: -1
Readout of the mechanical power applied to the motor shaft.
Parameter 16-24 Calibrated Stator Resistance
Table 597: Parameter 16-24 Calibrated Stator Resistance
16-24 Calibrated Stator Resistance
Default Value: 0.0000 Ohm
Conversion Index: -4
Shows the calibrated stator resistance.
Parameter 16-25 Torque [Nm] High
Table 598: Parameter 16-25 Torque [Nm] High
16-25 Torque [Nm] High
Default Value: 0 Nm
Conversion Index: -1
Danfoss A/S © 2021.08
Parameter Type: Range, 0 - 65535
Data Type: Uint16
Parameter Type: Range, -200 - 200%
Data Type: Int16
Parameter Type: Range, -200 - 200%
Data Type: Int16
Parameter Type: Range, 0 - 10000 kW
Data Type: Int32
Parameter Type: Range, 0.0000 - 100.0000 Ohm
Data Type: Uint32
Parameter Type: Range, -200000000 - 200000000 Nm
Data Type: Int32
Parameter Descriptions
Setup: All set-ups
Change during operation: True
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: True
Setup: All set-ups
Change during operation: True
Setup: All set-ups
Change during operation: False
AU373327181955en-000101 / 130R1208 | 305
