VLT® AutomationDrive EZ FC 321
Programming Guide
Option
[54] 24V encoder sim
[55] Pulse output
[58] Actual position
[59] Actual position 4–
20 mA
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic Rule 1
[72] Logic Rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
Danfoss A/S © 2021.08
Function
Digital outputs 27 and 29 simulate a single-signal HTL encoder. Select source for the signal gener-
ation in parameter 5-78 Term 27/29 Encoder Sim.
See parameter group 13-1* Comparators. If comparator 0 is evaluated as true, the output goes
high. Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 1 is evaluated as true, the output goes
high. Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 2 is evaluated as true, the output goes
high. Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 3 is evaluated as true, the output goes
high. Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 4 is evaluated as true, the output goes
high. Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 5 is evaluated as true, the output goes
high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 0 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 1 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 2 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 3 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 4 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 5 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[38] Set dig. out. A high is executed. The output goes low whenever the smart logic action [32] Set
dig. out. A low is executed.
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[39] Set dig. out. B high is executed. The output goes low whenever the smart logic action [33] Set
dig. out. B low is executed.
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[40] Set dig. out. C high is executed. The output goes low whenever the smart logic action [34] Set
dig. out. C low is executed.
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[41] Set dig. out. D high is executed. The output goes low whenever the smart logic action [35] Set
dig. out. D low is executed.
Parameter Descriptions
