VLT® AutomationDrive EZ FC 321
Programming Guide
Digital input function
Reset Counter B
Mech. brake feedb.
Mech. brake feedb. inv.
PID error inv.
PID reset I-part
PID enable
PTC card 1
PROFIdrive OFF2
PROFIdrive OFF3
Light-load detection
Evacuation
Mains loss
Mains loss inverse
Start edge triggered
Power limit mot.
Power limit gen.
Power limit both
Light load + evacuation
standard terminals are 18, 19, 27, 29, 32, and 33.
Functions dedicated to only 1 digital input are stated in the associated parameter.
All digital inputs can be programmed to these functions:
Table 283: Digital Inputs, Function Descriptions - 1
Option Function
[0] No operation No reaction to signals transmitted to the terminal.
[1] Reset Resets the drive after a trip/alarm. Not all alarms can be reset.
[2] Coast inverse (Default digital input 27): Coast stop, inverted input (NC). The drive leaves the motor in free mode. Logic
0⇒coast stop.
[3] Coast and re- Reset and coast stop inverted input (NC). Leaves the motor in free mode and resets the drive. Logic
set inverse 0⇒coast stop and reset.
[4] Quick stop in-
Inverted input (NC). Generates a stop in accordance with quick stop ramp time set in parameter 3-81
verse
Quick Stop Ramp Time. When the motor stops, the shaft is in free mode. Logic 0⇒quick stop.
[5] DC brake in- Inverted input for DC brake (NC). Stops motor by energizing it with a DC current for a certain time peri-
verse od. See parameter 2-01 DC Brake Current to parameter 2-03 DC Brake Cut In Speed [RPM]. The function is
only active when the value in parameter 2-02 DC Braking Time is different from 0. Logic 0⇒DC brake.
[6] Stop inverse
Stop inverted function. Generates a stop function when the selected terminal goes from logical level 1 to
logical level 0.
144 | Danfoss A/S © 2021.08
Select Terminal
[65] All
[70] All
[71] All
[72] All
[73] All
[74] All
[80] All
[91] All
[92] All
[94] All
[95] All
[96] 32, 33
[97] 32, 33
[98] All
[231] All
[232] All
[233] All
[234] All
AU373327181955en-000101 / 130R1208
Parameter Descriptions
