Interfaces
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Create a new WAN, or edit an existing one:
To create a new WAN, see
n
To edit an existing WAN, change to the WAN's node in the configuration schema. For
n
example, for a WAN named my_wan, change to the my_wan node in the configuration
schema:
(config)> network interface my_wan
(config network interface my_wan)>
4. Enable SureLink. SureLink can be enabled for both IPv4 and IPv6 configurations. By default,
SureLink is enabled for IPv4 for the preconfigured WAN. It is disabled for IPv6.
(config network interface my_wan> ipv4 surelink enable true
(config network interface my_wan)>
5. Set the device to reboot when the interface is considered to have failed:
(config network interface my_wan ipv4 surelink)> reboot true
(config network interface my_wan ipv4 surelink>
Note
If both the restart and reboot parameters are enabled, the reboot parameter takes
precedence.
6. Add a test target:
(config network interface my_wan)> add ipv4 surelink target end
(config network interface my_wan ipv4 surelink target 0)>
7. Set the test type:
(config network interface my_wan ipv4 surelink target 0)> test value
(config network interface my_wan ipv4 surelink target 0)>
where value is one of:
ping: Tests connectivity by sending an ICMP echo request to a specified hostname or IP
n
address.
Specify the hostname or IP address:
l
(Optional) Set the size, in bytes, of the ping packet:
l
Digi Connect EZ Mini User Guide
Configure a Wide Area Network
(config network interface my_wan ipv4 surelink target 0)> ping_
host host
(config network interface my_wan ipv4 surelink target 0)>
Wide Area Networks (WANs)
(WAN).
62
