3.24 Parameters: 26-** Analog I/O Option MCB 109

VLT ® Analog I/O Option MCB 109 extends the functionality of VLT
additional, programmable analog inputs and outputs. This could be especially useful in building management system instal-
lations where the frequency converter may be used as de-central I/O, obviating the need for an outstation and thus
reducing cost.
3 3
T
Illustration 3.88 Analog I/O Option MCB 109
Analog I/O Carsd
X42 1 2 3
Illustration 3.89 Analog I/O Option MCB 109
Illustration 3.88 a typical air handling unit (AHU). As can be seen, the addition of the analog I/O option offers the possibility
to control all of the functions from the frequency converter, such as inlet-, return- and exhaust dampers, or heating/cooling
coils with temperature and pressure measurements being read by the frequency converter.
