Introduction
The MicroBlaze™ Processor Reference Guide provides information about the 32-bit soft processor,
MicroBlaze, which is part of the Embedded Processor Development Kit (EDK). The document is
intended as a guide to the MicroBlaze hardware architecture.

Guide Contents

This guide contains the following chapters:
•
•
•
•
•
MicroBlaze Processor Reference Guide
UG081 (v14.7)
Chapter 2, MicroBlaze Architecture,
information on Big-Endian and Little-Endian bit-reversed format, 32-bit general purpose
registers, cache software support, and Fast Simplex Link interfaces.
Chapter 3, MicroBlaze Signal Interface Description,
that can be used to connect MicroBlaze.
Chapter 4, MicroBlaze Application Binary Interface,
Interface important for developing software in assembly language for the soft processor.
Chapter 5, MicroBlaze Instruction Set Architecture,
instructions for the Instruction Set Architecture of MicroBlaze.
Appendix A, Additional Resources,
resources.
www.xilinx.com
contains an overview of MicroBlaze features as well as
describes the types of signal interfaces
describes the Application Binary
provides notation, formats, and
provides links to EDK documentation and additional
