Chapter 2: MicroBlaze Architecture
•
•
•
•
•
•
•
•
•
Should an Instruction Bus Exception, Illegal Opcode Exception or Data Bus Exception occur when
C_FAULT_TOLERANT is set to 1, and an exception is in progress (i.e. MSR[EIP] set and MSR[EE]
cleared), the pipeline is halted, and the external signal MB_Error is set.
68
Send Feedback
The data side local memory (DLMB) can only cause instruction bus exception when
♦
C_FAULT_TOLERANT is set to 1, and either an uncorrectable error occurs in the LMB
memory, as indicated by the DUE signal, or C_ECC_USE_CE_EXCEPTION is set to 1
and a correctable error occurs in the LMB memory, as indicated by the DCE signal. An
error can occur for all read accesses, and for byte and halfword write accesses.
The CacheLink (DXCL) interfaces cannot cause data bus exceptions.
♦
Unaligned Exception
The unaligned exception is caused by a word access where the address to the data bus has bits
30 or 31 set, or a half-word access with bit 31 set.
Divide Exception
The divide exception is caused by an integer division (idiv or idivu) where the divisor is zero,
or by a signed integer division (idiv) where overflow occurs (-2147483648 / -1).
FPU Exception
An FPU exception is caused by an underflow, overflow, divide-by-zero, illegal operation, or
denormalized operand occurring with a floating point instruction.
Underflow occurs when the result is denormalized.
♦
♦ Overflow occurs when the result is not-a-number (NaN).
The divide-by-zero FPU exception is caused by the rA operand to fdiv being zero when rB
♦
is not infinite.
Illegal operation is caused by a signaling NaN operand or by illegal infinite or zero
♦
operand combinations.
Privileged Instruction Exception
The Privileged Instruction exception is caused by an attempt to execute a privileged instruction
in User Mode.
Stack Protection Violation Exception
A Stack Protection Violation exception is caused by executing a load or store instruction using
the stack pointer (register R1) as rA with an address outside the stack boundaries defined by the
special Stack Low and Stack High registers, causing a stack overflow or a stack underflow.
Data Storage Exception
The Data Storage exception is caused by an attempt to access data in memory that results in a
memory-protection violation.
Instruction Storage Exception
The Instruction Storage exception is caused by an attempt to access instructions in memory that
results in a memory-protection violation.
Data TLB Miss Exception
The Data TLB Miss exception is caused by an attempt to access data in memory, when a valid
Translation Look-Aside Buffer entry is not present, and virtual protected mode is enabled.
Instruction TLB Miss Exception
The Instruction TLB Miss exception is caused by an attempt to access instructions in memory,
when a valid Translation Look-Aside Buffer entry is not present, and virtual protected mode is
enabled.
