Table 3-18: MPD Parameters (Continued)
Parameter Name
C_AVOID_PRIMITIVES
C_PVR
C_PVR_USER1
C_PVR_USER2
C_RESET_MSR
C_INSTANCE
C_D_PLB
C_D_AXI
C_D_LMB
C_I_PLB
C_I_AXI
C_I_LMB
C_USE_BARREL
C_USE_DIV
C_USE_HW_MUL
MicroBlaze Processor Reference Guide
UG081 (v14.7)
Feature/Description
Disallow FPGA primitives
0 = None
1 = SRL
2 = LUTRAM
3 = Both
Processor version register
mode selection
0 = None
1 = Basic
2 = Full
Processor version register
USER1 constant
Processor version register
USER2 constant
Reset value for MSR
register
Instance Name
Data side PLB interface
Data side AXI interface
Data side LMB interface
Instruction side PLB
interface
Instruction side AXI
interface
Instruction side LMB
interface
Include barrel shifter
Include hardware divider
Include hardware
multiplier
0 = None
1 = Mul32
2 = Mul64
