Exception Status Register (ESR)
The Exception Status Register contains status bits for the processor. When read with the MFS
instruction, the ESR is specified by setting Sa = 0x0005. The ESR register is illustrated in
Figure
Exception Specific Status (ESS).
Table 2-11: Exception Status Register (ESR)
0:18
19
20:26
27:31
MicroBlaze Processor Reference Guide
UG081 (v14.7)
2-6, Table 2-11 provides bit descriptions and reset values, and
↑
RESERVED
Figure 2-6: ESR
Bits Name
Reserved
DS Delay Slot Exception.
0 = not caused by delay slot instruction
1 = caused by delay slot instruction
Read-only
ESS Exception Specific Status
For details refer to
Read-only
EC Exception Cause
00000 = Stream exception
00001 = Unaligned data access exception
00010 = Illegal op-code exception
00011 = Instruction bus error exception
00100 = Data bus error exception
00101 = Divide exception
00110 = Floating point unit exception
00111 = Privileged instruction exception
00111 = Stack protection violation exception
10000 = Data storage exception
10001 = Instruction storage exception
10010 = Data TLB miss exception
10011 = Instruction TLB miss exception
Read-only
