Chapter 3: MicroBlaze Signal Interface Description
Table 3-18: MPD Parameters (Continued)
Parameter Name
C_M_AXI_IP_
THREAD_ID_WIDTH
C_M_AXI_IP_DATA_WIDTH
C_M_AXI_IP_ADDR_WIDTH
C_M_AXI_IP_
SUPPORTS_THREADS
C_M_AXI_IP_SUPPORTS_READ
C_M_AXI_IP_SUPPORTS_WRITE
C_M_AXI_IP_SUPPORTS_
NARROW_BURST
C_M_AXI_IP_PROTOCOL
C_INTERCONNECT_
M_AXI_IP_READ_ISSUING
C_M_AXI_DC_
THREAD_ID_WIDTH
C_M_AXI_DC_DATA_WIDTH
C_M_AXI_DC_ADDR_WIDTH
C_M_AXI_DC_
SUPPORTS_THREADS
C_M_AXI_DC_SUPPORTS_READ
C_M_AXI_DC_SUPPORTS_WRITE
C_M_AXI_DC_SUPPORTS_
NARROW_BURST
146
Send Feedback
Feature/Description
Instruction side AXI
thread ID width
Instruction side AXI data
width
Instruction side AXI
address width
Instruction side AXI uses
threads
Instruction side AXI
support for read accesses
Instruction side AXI
support for write accesses
Instruction side AXI
narrow burst support
Instruction side AXI
protocol
Instruction side AXI read
accesses issued
Data cache AXI ID width
Data cache AXI data width
Data cache AXI address
width
Data cache AXI uses
threads
Data cacheAXI support for
read accesses
Data cache AXI support
for write accesses
Data cache AXI narrow
burst support
www.xilinx.com
EDK
Allowable Default Tool
Values Value Assig
ned
1 1
32 32
32 32
0 0
1 1
0 0
0 0
AXI4
AXI4LITE
LITE
1 1
1 1
32, 64, 128,
32
256, 512
32 32
0 0
1 1
1 1
0 0
