Foundry Switch and Router Installation and Configuration Guide
The <num> parameter lets you display the table beginning with a specific entry number.
This Field...
Static ARP table size
Index
IP Address
MAC Address
Port
USING THE WEB MANAGEMENT INTERFACE
You cannot display the static ARP table using the Web management interface.
Displaying the Forwarding Cache
To display the IP forwarding cache, use one of the following methods.
NOTE: To display only the forwarding cache entries for aggregated default network routes, see "Displaying the
Forwarding Cache Entries for Default Routes" on page 15-64.
USING THE CLI
To display the IP forwarding cache, enter the following command at any CLI level:
BigIron> show ip cache
Total number of cache entries: 3
D:Dynamic P:Permanent
W:Wait ARP I:ICMP Deny
IP Address
1 192.168.1.11
2 192.168.1.255
3 255.255.255.255
Syntax: show ip cache [<ip-addr>] | [<num>]
The <ip-addr> parameter displays the cache entry for the specified IP address.
The <num> parameter displays the cache beginning with the row following the number you enter. For example, to
begin displaying the cache at row 10, enter the following command: show ip cache 9.
15 - 92
Table 15.13: CLI Display of Static ARP Table
Displays...
The maximum number of static entries that can be configured on the
device using the current memory allocation. The range of valid
memory allocations for static ARP entries is listed after the current
allocation. To change the memory allocation for static ARP entries,
see "Changing the Maximum Number of Entries the Static ARP Table
Can Hold" on page 15-33.
The number of this entry in the table. You specify the entry number
when you create the entry.
The IP address of the device.
The MAC address of the device.
The port attached to the device the entry is for.
F:Forward U:Us C:Complex Filter
K:Drop R:Fragment
Next Hop MAC
DIRECT 0000.0000.0000
DIRECT 0000.0000.0000
DIRECT 0000.0000.0000
S:Snap Encap
Type Port
PU n/a
PU n/a
PU n/a
Vlan Pri
0
0
0
December 2000
