Foundry Switch and Router Installation and Configuration Guide
NOTE: The first address entered will be the primary DNS gateway address. The other addresses will be
used in chronological order, left to right, if the primary address is available.
5. Click the Apply button to save the change to the device's running-config file.
6. Select the Save link at the bottom of the dialog. Select Yes when prompted to save the configuration change
to the startup-config file on the device's flash memory.
Using a DNS Name To Initiate a Trace Route
EXAMPLE:
Suppose you want to trace the route from a Foundry Layer 2 Switch to a remote server identified as NYC02 on
domain newyork.com. Because the newyork.com domain is already defined on the Layer 2 Switch, you need to
enter only the host name, NYC02, as noted below.
USING THE CLI
FastIron# traceroute nyc02
Syntax: traceroute <host-ip-addr> [maxttl <value>] [minttl <value>] [numeric] [timeout <value>]
[source-ip <ip addr>]
The only required parameter is the IP address of the host at the other end of the route. See the Foundry Switch
and Router Command Line Interface Reference for information about the parameters.
After you enter the command, a message indicating that the DNS query is in process and the current gateway
address (IP address of the domain name server) being queried appear on the screen:
Type Control-c to abort
Sending DNS Query to 209.157.22.199
Tracing Route to IP node 209.157.22.80
To ABORT Trace Route, Please use stop-traceroute command.
Traced route to target IP node 209.157.22.80:
IP Address
207.95.6.30
NOTE: In the above example, 209.157.22.199 is the IP address of the domain name server (default DNS
gateway address), and 209.157.22.80 represents the IP address of the NYC02 host.
Figure 15.9 Querying a host on the newyork.com domain
15 - 78
Round Trip Time1
93 msec
Domain Name Server
[
newyork.com
207.95.6.199
Link Link
Activity
Activity
Console
Power
nyc02
...
nyc01
...
Round Trip Time2
121 msec
nyc01
nyc02
FastIron
