Foundry Switch and Router Installation and Configuration Guide
Table 15.17: CLI Display of IP Traffic Statistics – Layer 3 Switch (Continued)
This Field...
out segments
retransmission
RIP statistics
The RIP statistics are derived from RFC 1058, "Routing Information Protocol".
requests sent
requests received
responses sent
responses received
unrecognized
bad version
bad addr family
bad req format
bad metrics
bad resp format
resp not from rip port
resp from loopback
packets rejected
USING THE WEB MANAGEMENT INTERFACE
To display IP traffic statistics:
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration panel is displayed.
2. Click on the plus sign next to Monitor in the tree view to list the monitoring options.
3. Click on the plus sign next to IP to list the IP monitoring options.
4. Click on the Traffic link to display the table.
15 - 100
Displays...
The number of TCP segments sent by the device.
The number of segments that this device retransmitted because the
retransmission timer for the segment had expired before the device at
the other end of the connection had acknowledged receipt of the
segment.
The number of requests this device has sent to another RIP router for
all or part of its RIP routing table.
The number of requests this device has received from another RIP
router for all or part of this device's RIP routing table.
The number of responses this device has sent to another RIP router's
request for all or part of this device's RIP routing table.
The number of responses this device has received to requests for all
or part of another RIP router's routing table.
This information is used by Foundry customer support.
The number of RIP packets dropped by the device because the RIP
version was either invalid or is not supported by this device.
The number of RIP packets dropped because the value in the
Address Family Identifier field of the packet's header was invalid.
The number of RIP request packets this router dropped because the
format was bad.
This information is used by Foundry customer support.
The number of responses to RIP request packets this router dropped
because the format was bad.
This information is used by Foundry customer support.
The number of RIP responses received from loopback interfaces.
This information is used by Foundry customer support.
December 2000
