NOTE: To display other types of forwarding cache entries, see "Displaying the Forwarding Cache" on page 15-
92.
USING THE CLI
To display the default route cache entries, enter the following command at any level of the CLI:
BigIron(config)# show ip dr-aggregate
Syntax: show ip dr-aggregate [<ip-addr>]
If you specify an IP address, only the entries for that destination are displayed.
Here is an example of the information displayed by this command.
BigIron(config)# show ip dr-aggregate
Total number of cache entries: 2
Start index: 1
W:Wait ARP I:ICMP Deny
IP Address
1 22.22.22.22
2 207.96.7.7
This example shows two entries. The prefix associated with each entry is displayed. Notice that the prefix lengths
in this example are different for each entry. The software selects a prefix length long enough to make the default
network route entry unambiguous, so that is does not conflict with other cache entries.
To display the entry for a specific destination, enter the destination address, as shown in the following example.
BigIron(config)# show ip dr-aggregate 207.96.7.7
Total number of cache entries: 2
Start index: 1
W:Wait ARP I:ICMP Deny
IP Address
1 207.96.7.7
This example shows the second entry from the previous example, but the entry row number is 1. The row number
identifies the row number in the displayed output. In addition, notice that the Total number of cache entries field
shows 2, as in the previous example. The number in this field indicates the total number of default route
aggregation entries in the forwarding cache.
USING THE WEB MANAGEMENT INTERFACE
You cannot display the default-route cache entries using the Web management interface.
Clearing the Forwarding Cache Entries for Default Routes
You can clear the default route entries from the IP forwarding cache. To do so, use the following CLI method.
NOTE: This command does not affect other types of forwarding cache entries.
USING THE CLI
To clear the default-route cache entries, enter the following command from the Privileged EXEC level of the CLI:
BigIron# clear ip dr-aggregate
Syntax: clear ip dr-aggregate
USING THE WEB MANAGEMENT INTERFACE
You cannot clear the entries using the Web management interface.
December 2000
D:Dynamic P:Permanent
K:Drop R:Fragment
Next Hop
/8 207.95.6.60
/12 207.95.6.60
D:Dynamic P:Permanent
K:Drop R:Fragment
Next Hop
/12 207.95.6.60
F:Forward U:Us C:Complex Filter
S:Snap Encap
MAC Type
0044.052e.4302 DF
0044.052e.4302 DF
F:Forward U:Us C:Complex Filter
S:Snap Encap
MAC Type
0044.052e.4302 DF
Configuring IP
Port Vlan Pri
1/1 1 0
1/1 1 0
Port Vlan Pri
1/1 1 0
