Foundry Switch and Router Installation and Configuration Guide
l4-real-server
l4-virtual-server
l4-server-port
mac
ip-route
ip-static-route
vlan
spanning-tree
mac-filter-port
mac-filter-sys
ip-subnet-port
session-limit
view
virtual-interface
Information for the configurable tables appears under the columns that are shown in bold type in this example. To
simplify configuration, the command parameter you enter to configure the table is used for the table name. For
example, to increase the capacity of the IP route table, enter the following commands:
BigIron(config)# system-max ip-route 120000
BigIron(config)# write memory
BigIron(config)# exit
BigIron# reload
NOTE: If you accidentally enter a value that is not within the valid range of values, the CLI will display the valid
range for you.
To increase the number of IP sub-net interfaces you can configure on each port on a NetIron Layer 3 Switch from
24 to 64, then increase the total number of IP interfaces you can configure on the device from 256 to 512, enter
the following commands:
NetIron(config)# system-max subnet-per-interface 64
NetIron(config)# write memory
NetIron(config)# exit
NetIron# reload
Syntax: system-max subnet-per-interface <num>
The <num> parameter specifies the maximum number of sub-net addresses per port and can be from 1 – 64. The
default is 24.
Syntax: system-max subnet-per-system <num>
The <num> parameter specifies the maximum number of sub-net addresses for the entire device and can be from
1 – 512. The default is 256.
NetIron(config)# system-max subnet-per-system 512
NetIron(config)# write memory
NetIron(config)# exit
NetIron# reload
USING THE WEB MANAGEMENT INTERFACE
To modify a table size using the Web management interface:
1. Log on to the device using a valid user name and password for read-write access. The System configuration
panel is displayed.
2. Select the Max-Parameter link to display the Configure System Parameter Maximum Value table. This table
lists the settings and valid ranges for all the configurable table sizes on the device.
10 - 72
1024 2048
256 512
2048 4096
8000 64000
128000 200000
512 2048
16 2048
32 128
32 512
64 1024
24 128
131072 500000
10 65535
255 2048
1024
256
2048
8000
128000
512
16
32
32
64
24
131072
10
255
