Displaying the Best BGP4 Routes
To display all the BGP4 routes in the Layer 3 Switch's BGP4 route table that are the best routes to their
destinations, enter a command such as the following at any level of the CLI:
BigIron(config-bgp-router)# show ip bgp routes best
Searching for matching routes, use ^C to quit...
Status A:AGGREGATE B:BEST b:NOT-INSTALLED-BEST C:CONFED_EBGP D:DAMPED
H:HISTORY I:IBGP L:LOCAL M:MULTIPATH S:SUPPRESSED
Network
1 4.2.42.0
2 4.2.43.0
3 7.7.7.0
4 38.38.38.0
13 102.0.0.0
Syntax: show ip bgp routes best
For information about the fields in this display, see Table 19.9 on page 19-110. The fields in this display also
appear in the show ip bgp display.
Displaying Those Best BGP4 Routes that Are Nonetheless Not in the IP Route Table
When the Layer 3 Switch has multiple routes to a destination from different sources (such as BGP4, OSPF, RIP, or
static routes), the Layer 3 Switch selects the route with the lowest administrative distance as the best route, and
installs that route in the IP route table.
To display the BGP4 routes are the "best" routes to their destinations but are not installed in the Layer 3 Switch's
IP route table, enter a command such as the following at any level of the CLI:
BigIron(config-bgp-router)# show ip bgp routes not-installed-best
Searching for matching routes, use ^C to quit...
Status A:AGGREGATE B:BEST b:NOT-INSTALLED-BEST C:CONFED_EBGP D:DAMPED
H:HISTORY I:IBGP L:LOCAL M:MULTIPATH S:SUPPRESSED
Network
1 7.7.7.0
Each of the displayed routes is a valid path to its destination, but the Layer 3 Switch received another path from a
different source (such as OSPF, RIP, or a static route) that has a lower administrative distance. The Layer 3
Switch always selects the path with the lowest administrative distance to install in the IP route table.
Notice that the route status in this example is the new status, "b". See Table 19.9 on page 19-110 for a
description.
Syntax: show ip bgp routes not-installed-best
For information about the fields in this display, see Table 19.9 on page 19-110. The fields in this display also
appear in the show ip bgp display.
NOTE: To display the routes that the Layer 3 Switch has selected as the best routes and installed in the IP route
table, display the IP route table using the show ip route command.
Displaying BGP4 Routes Whose Destinations Are Unreachable
To display BGP4 routes whose destinations are unreachable using any of the BGP4 paths in the BGP4 route
table, enter a command such as the following at any level of the CLI:
BigIron(config-bgp-router)# show ip bgp routes unreachable
Searching for matching routes, use ^C to quit...
Status A:AGGREGATE B:BEST b:NOT-INSTALLED-BEST C:CONFED_EBGP D:DAMPED
H:HISTORY I:IBGP L:LOCAL M:MULTIPATH S:SUPPRESSED
Network
1 8.8.8.0
Syntax: show ip bgp routes unreachable
December 2000
ML Next Hop Metric
24 192.168.4.211
24 192.168.4.211
24 192.168.4.211 0
24 192.168.4.211 0
24 200.1.1.10 12
ML Next Hop Metric
24 192.168.4.211 0
ML Next Hop Metric
24 192.168.5.1 0
Configuring BGP4
LocPrf Weight Status
101 0 B
101 0 B
101 0 b
101 0 B
101 32768 BL
LocPrf Weight Status
101 0 b
LocPrf Weight Status
101 0
