Displaying Multicast Neighbor Information
To display information about the Layer 3 Switch's IP Multicast neighbors, use either of the following methods.
USING THE CLI
To display information about the Layer 3 Switch's PIM neighbors, enter the following command at any CLI level:
BigIron(config-pim-router)# show ip pim nbr
Port Neighbor
e3/8 207.95.8.10
Port Neighbor
v1 207.95.6.2
Syntax: show ip pim nbr
This display shows the following information.
This Field...
Port
Neighbor
Holdtime sec
Age sec
UpTime sec
USING THE WEB MANAGEMENT INTERFACE
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration panel is displayed.
2. Click on the plus sign next to Monitor in the tree view.
3. Click on the plus sign next to PIM in the tree view to expand the list of PIM option links.
4. Click on the Neighbor link to display the IP interface table.
Displaying the PIM Flow Cache
To display the PIM flow cache, use the following CLI method.
USING THE CLI
To display the PIM flow cache, enter the following command at any CLI level:
December 2000
Holdtime Age UpTime
sec sec sec
180 60 900
Holdtime Age UpTime
sec sec sec
180 60 900
Displays...
The interface through which the Layer 3 Switch is connected to the
neighbor.
The IP interface of the PIM neighbor interface.
Indicates how many seconds the neighbor wants this Layer 3 Switch
to hold the entry for this neighbor in memory. The neighbor sends the
Hold Time in its Hello packets.
• If the Layer 3 Switch receives a new Hello packet before the
Hold Time received in the previous packet expires, the Layer
3 Switch updates its table entry for the neighbor.
• If the Layer 3 Switch does not receive a new Hello packet
from the neighbor before the Hold time expires, the Layer 3
Switch assumes the neighbor is no longer available and
removes the entry for the neighbor.
The number of seconds since the Layer 3 Switch received the last
hello message from the neighbor.
The number of seconds the PIM neighbor has been up. This timer
starts when the Layer 3 Switch receives the first Hello messages from
the neighbor.
Configuring IP Multicast Protocols
18 - 25
