Foundry Switch and Router Installation and Configuration Guide
This Field...
RIB_out
Communities
USING THE WEB MANAGEMENT INTERFACE
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration panel is displayed.
2. Click on the plus sign next to Monitor in the tree view to expand the list of monitoring options.
3. Click on the plus sign next to BGP in the tree view to expand the list of BGP option links.
4. Click on the Routes link to display the BGP Routes panel.
Displaying BGP4 Route-Attribute Entries
The route-attribute entries table lists the sets of BGP4 attributes stored in the router's memory. Each set of
attributes is unique and can be associated with one or more routes. In fact, the router typically has fewer route
attribute entries than routes. To display the route-attribute entries table, use one of the following methods.
USING THE CLI
To display the IP route table, enter the following command:
BigIron# show ip bgp attribute-entries
Syntax: show ip bgp attribute-entries
Here is an example of the information displayed by this command. A zero value indicates that the attribute is not
set.
BigIron# show ip bgp attribute-entries
Total number of BGP Attribute Entries: 7753
1 Next Hop
Originator:0.0.0.0
Aggregator:AS Number :0
Local Pref:100
AS Path
2 Next Hop
Originator:0.0.0.0
Aggregator:AS Number :0
Local Pref:100
AS Path
remaining 7751 entries not shown...
This display shows the following information.
This Field...
Total number of BGP Attribute Entries
19 - 114
Table 19.10: BGP4 Network Information (Continued)
Displays...
The number of neighbors to which the route has been or will be
advertised. This is the number of times the route has been selected
as the best route and placed in the Adj-RIB-Out (outbound queue) for
a BGP4 neighbor.
The communities the route is in.
:192.168.11.1
:(65002) 65001 4355 2548 3561 5400 6669 5548
:192.168.11.1
:(65002) 65001 4355 2548
Table 19.11: BGP4 Route-Attribute Entries Information
Displays...
The number of routes contained in this router's BGP4 route table.
Metric :0
Cluster List:None
Router-ID:0.0.0.0
Communities:Internet
Metric :0
Cluster List:None
Router-ID:0.0.0.0
Communities:Internet
Origin:IGP
Atomic:FALSE
Origin:IGP
Atomic:FALSE
