This completes the configuration for NetIron-A. The configuration for NetIron-B and C is very similar except for a
few issues.
• IP sub-nets and IPX networks configured on NetIron-B and NetIron-C must be unique across the entire
network, except for the backbone port-based VLANs 5, 6, and 7 where the sub-net is the same but the IP
address must change.
• There is no need to change the default priority of STP within VLAN 4.
• There is no need to include a virtual router interface within VLAN 4.
• The backbone VLAN between NetIron-B and NetIron-C must be the same at both ends and requires a new
VLAN ID. The VLAN ID for this port-based VLAN is VLAN 7.
Configuration for NetIron-B
Enter the following commands to configure NetIron-B.
NetIron> en
No password has been assigned yet...
NetIron# config t
NetIron(config)# hostname NetIron-B
NetIron-B(config)# router ospf
NetIron-B(config-ospf-router)# area 0.0.0.0 normal
NetIron-B(config-ospf-router)# router ipx
NetIron-B(config-ospf-router)# vlan 2 name IP-Subnet_1.1.6.0/24
NetIron-B(config-vlan-2)# untag e1 to 4
NetIron-B(config-vlan-2)# no spanning-tree
NetIron-B(config-vlan-2)# router-interface ve1
NetIron-B(config-vlan-2)# other-proto name block-other-protocols
NetIron-B(config-vlan-other-proto)# no dynamic
NetIron-B(config-vlan-other-proto)# exclude e1 to 4
NetIron-B(config-vlan-other-proto)# int ve1
NetIron-B(config-vif-1)# ip addr 1.1.6.1/24
NetIron-B(config-vif-1)# ip ospf area 0.0.0.0
NetIron-B(config-vif-1)# vlan 8 name IPX_Network6
NetIron-B(config-vlan-8)# untag e 5 to 8
NetIron-B(config-vlan-8)# no span
NetIron-B(config-vlan-8)# router-int ve2
NetIron-B(config-vlan-8)# other-proto name block-other-protocols
NetIron-B(config-vlan-other-proto)# no dynamic
NetIron-B(config-vlan-other-proto)# exclude e5 to 8
NetIron-B(config-vlan-other-proto)# int ve2
NetIron-B(config-vif-2)# ipx net 6 ethernet_802.3
NetIron-B(config-vif-2)# vlan 3 name IP_Sub_&_IPX_Net_VLAN
NetIron-B(config-vlan-3)# untag e9 to 16
NetIron-B(config-vlan-3)# no spanning-tree
NetIron-B(config-vlan-3)# ip-subnet 1.1.7.0/24
NetIron-B(config-vlan-ip-subnet)# static e9 to 12
NetIron-B(config-vlan-ip-subnet)# router-interface ve3
NetIron-B(config-vlan-ip-subnet)# ipx-network 7 ethernet_802.3
NetIron-B(config-vlan-ipx-network)# static e13 to 16
NetIron-B(config-vlan-ipx-network)# router-interface ve4
NetIron-B(config-vlan-ipx-network)# other-proto name block-other-protocols
NetIron-B(config-vlan-other-proto)# exclude e9 to 16
NetIron-B(config-vlan-other-proto)# no dynamic
NetIron-B(config-vlan-other-proto)# interface ve 3
NetIron-B(config-vif-3)# ip addr 1.1.7.1/24
NetIron-B(config-vif-3)# ip ospf area 0.0.0.0
NetIron-B(config-vif-3)# int ve4
NetIron-B(config-vif-4)# ipx network 7 ethernet_802.3
NetIron-B(config-vif-4)# vlan 4 name Bridged_ALL_Protocols
