Foundry Switch and Router Installation and Configuration Guide
USING THE WEB MANAGEMENT INTERFACE
To assign an IP address and mask to a router interface:
1. Log on to the device using a valid user name and password for read-write access. The System configuration
dialog is displayed.
2. Select the IP Address link. The IP addresses already configured on the device are listed in a table. Select
Add IP Address to display the following panel.
3. Select the port (and slot if applicable) on which you want to configure the address.
NOTE: This example shows the panel for configuring an address on a Layer 3 Switch. On a Layer 2 Switch,
the IP address is global and applies to all the Layer 2 Switch's ports. Thus, you do not need to select a port.
4. Enter the IP address and network mask.
5. If the port already has an IP address configured, select the Secondary checkbox.
6. Click the Add button to save the change to the device's running-config file.
7. Select the Save link at the bottom of the dialog. Select Yes when prompted to save the configuration change
to the startup-config file on the device's flash memory.
NOTE: You also can access the dialog for saving configuration changes by clicking on Command in the tree
view, then clicking on Save to Flash.
Assigning an IP Address to a POS Port
Assigning an IP address to a POS port is similar to assigning an IP address to an Ethernet port.
NOTE: To configure other Layer 3 parameters for POS ports, see "Configuring POS Interfaces" on page 6-5.
USING THE CLI
To add an IP address to POS interface 2/1, enter the following commands:
BigIron(config)# interface pos 2/1
BigIron(config-posif-2/1)# ip address 209.157.22.26/24
BigIron(config-posif-2/1)# write memory
Syntax: [no] ip address <ip-addr> <ip-mask> [secondary]
or
Syntax: [no] ip address <ip-addr>/<mask-bits> [secondary]
15 - 20 December 2000
