This Field...
Peer Address
State
KA In
KA Out
SA In
SA Out
NOT In
NOT Out
USING THE WEB MANAGEMENT INTERFACE
You cannot display MSDP information using the Web management interface.
Displaying Peer Information
To display summary MSDP peer information, use the following CLI method.
USING THE CLI
To display MSDP peer information, use the following CLI method.
BigIron(config-msdp-router)# show ip msdp peer
Total number of MSDP Peers: 2
IP Address
1 206.251.17.30
Keep Alive Time
60
Keep Alive
Notifications
Source-Active
Last Connection Reset Reason:Reason Unknown
Notification Message Error Code Received:Unspecified
Notification Message Error SubCode Received:Not Applicable
December 2000
MSDP Summary Information
Displays...
The IP address of the peer's interface with the Layer 3 Switch
The state of the MSDP router's connection with the peer. The state
can be one of the following:
• CONNECTING – The session is in the active open state.
• ESTABLISHED – The MSDP session is fully up.
• INACTIVE – The session is idle.
• LISTENING – The session is in the passive open state.
The number of MSDP Keepalive messages the MSDP router has
received from the peer
The number of MSDP Keepalive messages the MSDP router has sent
to the peer
The number of Source Active messages the MSDP router has
received from the peer
The number of Source Active messages the MSDP router has sent to
the peer
The number of Notification messages the MSDP router has received
from the peer
The number of Notification messages the MSDP router has sent to
the peer
State
ESTABLISHED
Hold Time
90
Message Sent
2
0
0
Configuring IP Multicast Protocols
Message Received
3
0
640
