Table 19.11: BGP4 Route-Attribute Entries Information (Continued)
This Field...
Next Hop
Metric
Origin
Originator
Cluster List
Aggregator
Atomic
Local Pref
Communities
AS Path
USING THE WEB MANAGEMENT INTERFACE
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration panel is displayed.
2. Click on the plus sign next to Monitor in the tree view to expand the list of monitoring options.
3. Click on the plus sign next to BGP in the tree view to expand the list of BGP option links.
4. Click on the Attributes link to display the BGP Attributes Entries panel.
December 2000
Displays...
The IP address of the next hop router for routes that have this set of
attributes.
The cost of the routes that have this set of attributes.
The source of the route information. The origin can be one of the
following:
• EGP – The routes with this set of attributes came to BGP through
EGP.
• IGP – The routes with this set of attributes came to BGP through
IGP.
• INCOMPLETE – The routes came from an origin other than one
of the above. For example, they may have been redistributed
from OSPF or RIP.
When BGP4 compares multiple routes to a destination to select the
best route, IGP is preferred over EGP and both are preferred over
INCOMPLETE.
The originator of the route in a route reflector environment.
The route-reflector clusters through which this set of attributes has
passed.
Aggregator information:
• AS Number shows the AS in which the network information in the
attribute set was aggregated. This value applies only to
aggregated routes and is otherwise 0.
• Router-ID shows the router that originated this aggregator.
Whether the network information in this set of attributes has been
aggregated and this aggregation has resulted in information loss.
• TRUE – Indicates information loss has occurred
• FALSE – Indicates no information loss has occurred
Note: Information loss under these circumstances is a normal part of
BGP4 and does not indicate an error.
The degree of preference for routes that use this set of attributes
relative to other routes in the local AS.
The communities that routes with this set of attributes are in.
The ASs through which routes with this set of attributes have passed.
The local AS is shown in parentheses.
