This display shows the following information.
Table 15.18: Web Display of IP Traffic Statistics – Layer 3 Switch
This Field...
IP statistics
Packets Received
Packets Sent
Packets Forwarded
Filtered
Fragmented
Reassembled
Bad Header
No Route
Unknown Protocols
No Buffer
Other Errors
ICMP statistics
Total Received
Total Sent
Received Errors
Sent Errors
Received Unreachable
Sent Unreachable
Received Time Exceed
Sent Time Exceed
Received Parameter
Sent Parameter
Received Source Quench
Sent Source Quench
December 2000
Displays...
The number of IP packets received by the device.
The number of IP packets originated and sent by the device.
The number of IP packets received from another device and
forwarded by this device.
The number of IP packets filtered by this device.
The number of IP packets fragmented by this device before sending
or forwarding them.
The number of fragmented IP packets received and re-assembled by
the device.
The number of packets dropped because they had a bad header.
The number of packets dropped because they had no route
information.
The number of packets dropped because they were using an
unknown protocol.
The number of packets dropped because the device ran out of buffer
space.
The number of packets dropped due to errors other than the ones
listed above.
The number of ICMP packets received by the device.
The number of ICMP packets sent by the device.
This information is used by Foundry customer support.
This information is used by Foundry customer support.
The number of Destination Unreachable messages received by the
device.
The number of Destination Unreachable messages sent by the
device.
The number of Time Exceeded messages received by the device.
The number of Time Exceeded messages sent by the device.
The number of Parameter Problem messages received by the device.
The number of Parameter Problem messages sent by the device.
The number of Source Quench messages received by the device.
The number of Source Quench messages sent by the device.
