Foundry Switch and Router Installation and Configuration Guide
3. Select the ARP Cache link to display the ARP cache.
This display shows the following information.
This Field...
Node
MAC Address
Type
Age
Port
Displaying IP Traffic Statistics
To display IP traffic statistics on a Layer 2 Switch, use one of the following methods.
USING THE CLI
To display IP traffic statistics, enter the following command at any CLI level:
FastIron# show ip traffic
IP Statistics
27 received, 24 sent
0 fragmented, 0 reassembled, 0 bad header
0 no route, 0 unknown proto, 0 no buffer, 0 other errors
ICMP Statistics
Received:
0 total, 0 errors, 0 unreachable, 0 time exceed
0 parameter, 0 source quench, 0 redirect, 0 echo,
0 echo reply, 0 timestamp, 0 timestamp rely, 0 addr mask
0 addr mask reply, 0 irdp advertisement, 0 irdp solicitation
Sent:
0 total, 0 errors, 0 unreachable, 0 time exceed
0 parameter, 0 source quench, 0 redirect, 0 echo,
0 echo reply, 0 timestamp, 0 timestamp rely, 0 addr mask
0 addr mask reply, 0 irdp advertisement, 0 irdp solicitation
UDP Statistics
0 received, 0 sent, 0 no port, 0 input errors
TCP Statistics
1 current active tcbs, 4 tcbs allocated, 0 tcbs freed 0 tcbs protected
0 active opens, 0 passive opens, 0 failed attempts
0 active resets, 0 passive resets, 0 input errors
27 in segments, 24 out segments, 0 retransmission
Syntax: show ip traffic
15 - 106
Table 15.21: Web Display of ARP Cache – Layer 2 Switch
Displays...
The IP address of the device.
The MAC address of the device.
The type, which is always Dynamic on Foundry Layer 2 Switches.
The device learns dynamic entries from incoming packet.
The number of minutes the entry has remained unused. If this value
reaches the ARP aging period, the entry is removed from the cache.
The port on which the entry was learned.
