Foundry Switch and Router Installation and Configuration Guide
Table 15.23: Web Display of IP Traffic Statistics – Layer 2 Switch (Continued)
This Field...
Sent Parameter
Received Source Quench
Sent Source Quench
Received Redirect
Sent Redirect
Received Echo
Sent Echo
Received Echo Reply
Sent Echo Reply
Received Timestamp
Sent Timestamp
Received Timestamp Reply
Sent Timestamp Reply
Received Address Mask
Sent Address Mask
Received Address Mask Reply
Sent Address Mask Reply
Received IRDP Advertisement
Sent IRDP Advertisement
Received IRDP Solicitation
Sent IRDP Solicitation
UDP statistics
Received
Sent
No Port
Input Errors
TCP statistics
The TCP statistics are derived from RFC 793, "Transmission Control Protocol".
Active Opens
15 - 110
Displays...
The number of Parameter Problem messages sent by the device.
The number of Source Quench messages received by the device.
The number of Source Quench messages sent by the device.
The number of Redirect messages received by the device.
The number of Redirect messages sent by the device.
The number of Echo messages received by the device.
The number of Echo messages sent by the device.
The number of Echo messages received by the device.
The number of Echo messages sent by the device.
The number of Timestamp messages received by the device.
The number of Timestamp messages sent by the device.
The number of Timestamp Reply messages received by the device.
The number of Timestamp Reply messages sent by the device.
The number of Address Mask Request messages received by the
device.
The number of Address Mask Request messages sent by the device.
The number of Address Mask Replies messages received by the
device.
The number of Address Mask Replies messages sent by the device.
The number of ICMP Router Discovery Protocol (IRDP)
Advertisement messages received by the device.
The number of IRDP Advertisement messages sent by the device.
The number of IRDP Solicitation messages received by the device.
The number of IRDP Solicitation messages sent by the device.
The number of UDP packets received by the device.
The number of UDP packets sent by the device.
The number of UDP packets dropped because the packet did not
contain a valid UDP port number.
This information is used by Foundry customer support.
The number of TCP connections opened by this device by sending a
TCP SYN to another device.
