Foundry Switch and Router Installation and Configuration Guide
Notification Message Error Code Transmitted:Unspecified
Notification Message Error SubCode Transmitted:Not Applicable
TCP Connection state: ESTABLISHED
Local host:
Remote host: 206.251.17.30, Remote Port: 639
ISentSeq:
SendWnd:
IRcvSeq:
TotalRcv:
Syntax: show ip msdp peer
This display shows the following information.
This Field...
Total number of MSDP peers
IP Address
State
Keep Alive Time
Hold Time
Keep Alive Message Sent
Keep Alive Message Received
Notifications Sent
Notifications Received
Source-Active Sent
Source-Active Received
Last Connection Reset Reason
18 - 34
206.251.17.29, Local
16927 SendNext:
16384 TotSent:
45252428 RcvNext:
10 RcvQue:
MSDP Peer Information
Displays...
The number of MSDP peers configured on the Layer 3 Switch
The IP address of the peer's interface with the Layer 3 Switch
The state of the MSDP router's connection with the peer. The state
can be one of the following:
• CONNECTING – The session is in the active open state.
• ESTABLISHED – The MSDP session is fully up.
• INACTIVE – The session is idle.
• LISTENING – The session is in the passive open state.
The keep alive time, which specifies how often this MSDP router
sends keep alive messages to the neighbor. The keep alive time is 60
seconds and is not configurable.
The hold time, which specifies how many seconds the MSDP router
will wait for a KEEPALIVE or UPDATE message from an MSDP
neighbor before deciding that the neighbor is dead. The hold time is
90 seconds and is not configurable.
The number of Keep Alive messages the MSDP router has sent to the
peer.
The number of Keep Alive messages the MSDP router has received
from the peer.
The number of Notification messages the MSDP router has sent to
the peer.
The number of Notification messages the MSDP router has received
from the peer.
The number of Source Active messages the MSDP router has sent to
the peer.
The number of Source Active messages the MSDP router has
received from the peer.
The reason the previous session with this neighbor ended.
Port: 8270
685654 TotUnAck:
668727 ReTrans:
45252438 RcvWnd:
0 SendQue:
0
1
16384
0
December 2000
