Displaying Nat Statistics - Foundry Networks Switch and Router Installation And Configuration Manual

BigIron(config)# show ip nat translation
Pro Inside global
--- 209.157.1.69
--- 209.157.1.72
Syntax: show ip nat translation
The show ip nat translation command shows the following information.
This Field...
Pro
Inside global
Inside local
Outside global
Outside local

Displaying NAT Statistics

To display NAT statistics, use the following CLI method.
USING THE CLI
To display the NAT statistics, enter the following command at any level of the CLI:
BigIron(config)# show ip nat statistics
Total translations: 10 (0 static, 10 dynamic)
Hits: 10 Misses: 1
Expired translations: 1
Dynamic mappings:
pool rtrpool: mask = 255.255.255.255
start 192.168.2.79 end 192.168.2.79
total addresses 1 overloaded
IP Fragments: saved 0, restored 0, timed out 0
Sess: Total 524288, Avail 524243, NAT 22
Inside global
192.168.2.79
December 2000
Inside local
10.10.10.69
10.10.10.2
Table 20.1: CLI Display of Active NAT Translations
Displays...
When Port Address Translation is enabled, this field indicates the
protocol NAT is using to uniquely identify the host. NAT can map the
same IP address to multiple hosts and use the protocol port to
distinguish among the hosts. This field can have one of the following
values:
• tcp – In addition to this IP address, NAT is associating a TCP port
with the host on the private network.
• udp – In addition to this IP address, NAT is associating a UDP
port with the host on the private network.
The Internet address mapped to the private address listed in the
Inside local field for inside NAT.
The private address mapped to the Internet private address listed in
the Inside global field for inside NAT.
The destination of the traffic. If Port Address Translation is enabled,
the TCP or UDP port also is shown.
In the current release, the same as Outside global.
Last Inside Local xmit pkts
10.10.100.18 62
Outside local
207.195.2.12 207.195.2.12
207.195.4.69 207.195.4.69
xmit bytes rx pkts
4012
Network Address Translation
Outside global
rx bytes
42 4285
20 - 9
cnt
10
