Foundry Switch and Router Installation and Configuration Guide
BigIronA(config-vlan-101)# exit
BigIronA(config)# vlan 102 by port
BigIronA(config-vlan-102)# tagged ethernet 2/1
BigIronA(config-vlan-102)# untagged ethernet 1/2
BigIronA(config-vlan-102)# exit
BigIronA(config)# vlan 103 by port
BigIronA(config-vlan-103)# tagged ethernet 2/1
BigIronA(config-vlan-103)# untagged ethernet 1/3
BigIronA(config-vlan-103)# exit
BigIronA(config)# vlan 104 by port
BigIronA(config-vlan-104)# tagged ethernet 2/1
BigIronA(config-vlan-104)# untagged ethernet 1/4
BigIronA(config-vlan-104)# exit
BigIronA(config)# vlan 105 by port
BigIronA(config-vlan-105)# tagged ethernet 2/1
BigIronA(config-vlan-105)# untagged ethernet 1/5
BigIronA(config-vlan-105)# exit
BigIronA(config)# write memory
Commands for Device B
The commands for configuring device B are identical to the commands for configuring device A. Notice that you
can use the same channel VLAN numbers on each device. The devices that aggregate the VLANs into a path can
distinguish between the identically named channel VLANs based on the ID of the path VLAN.
BigIronB(config)# vlan 101 by port
BigIronB(config-vlan-101)# tagged ethernet 2/1
BigIronB(config-vlan-101)# untagged ethernet 1/1
BigIronB(config-vlan-101)# exit
BigIronB(config)# vlan 102 by port
BigIronB(config-vlan-102)# tagged ethernet 2/1
BigIronB(config-vlan-102)# untagged ethernet 1/2
BigIronB(config-vlan-102)# exit
BigIronB(config)# vlan 103 by port
BigIronB(config-vlan-103)# tagged ethernet 2/1
BigIronB(config-vlan-103)# untagged ethernet 1/3
BigIronB(config-vlan-103)# exit
BigIronB(config)# vlan 104 by port
BigIronB(config-vlan-104)# tagged ethernet 2/1
BigIronB(config-vlan-104)# untagged ethernet 1/4
BigIronB(config-vlan-104)# exit
BigIronB(config)# vlan 105 by port
BigIronB(config-vlan-105)# tagged ethernet 2/1
BigIronB(config-vlan-105)# untagged ethernet 1/5
BigIronB(config-vlan-105)# exit
BigIronB(config)# write memory
Commands for Device C
Since device C is aggregating channel VLANs from devices A and B into a single path, you need to change the tag
type and enable VLAN aggregation.
BigIronC(config)# tag-type 9100
BigIronC(config)# aggregated-vlan
BigIronC(config)# vlan 101 by port
BigIronC(config-vlan-101)# tagged ethernet 4/1
BigIronC(config-vlan-101)# untagged ethernet 3/1
BigIronC(config-vlan-101)# exit
BigIronC(config)# vlan 102 by port
BigIronC(config-vlan-102)# tagged ethernet 4/1
BigIronC(config-vlan-102)# untagged ethernet 3/2
25 - 52 December 2000
