Foundry Switch and Router Installation and Configuration Guide
FastIron-B(config-vlan-ip-proto)# exclude e5 to 8
FastIron-B(config-vlan-ip-proto)# ipx-proto name Blue
FastIron-B(config-vlan-ipx-proto)# no dynamic
FastIron-B(config-vlan-ipx-proto)# static e5 to 8 e25 to 26
FastIron-B(config-vlan-ipx-proto)# exclude e1 to 4
FastIron-B(config-vlan-other-proto)# vlan 3 name IP-Sub_IPX-Net_VLANs
FastIron-B(config-vlan-3)# untag e9 to 16
FastIron-B(config-vlan-3)# tag e25 to 26
FastIron-B(config-vlan-3)# spanning-tree
FastIron-B(config-vlan-3)# spanning-tree priority 500
FastIron-B(config-vlan-3)# ip-sub 1.1.1.0/24 name Green
FastIron-B(config-vlan-ip-subnet)# no dynamic
FastIron-B(config-vlan-ip-subnet)# static e9 to 12 e25 to 26
FastIron-B(config-vlan-ip-subnet)# exclude e13 to 16
FastIron-B(config-vlan-ip-subnet)# ipx-net 1 ethernet_802.3 name Brown
FastIron-B(config-vlan-ipx-network)# no dynamic
FastIron-B(config-vlan-ipx-network)# static e13 to 16 e25 to 26
FastIron-B(config-vlan-ipx-network)# exclude e9 to 12
FastIron-B(config-vlan-ipx-network)# vlan 4 name Purple_ALL-Protocols
FastIron-B(config-vlan-4)# untag e17 to 24
FastIron-B(config-vlan-4)# tag e25 to 26
FastIron-B(config-vlan-4)# spanning-tree
Configuring FastIron-C
Enter the following commands to configure FastIron-C:
FastIron# config t
FastIron(config)# host FastIron-C
FastIron-C(config)# vlan 2 name IP_IPX_Protocol
FastIron-C(config-vlan-2)# untag e1 to 8
FastIron-C(config-vlan-2)# tag e25 to 26
FastIron-C(config-vlan-2)# spanning-tree
FastIron-C(config-vlan-2)# ip-proto name Red
FastIron-C(config-vlan-ip-proto)# no dynamic
FastIron-C(config-vlan-ip-proto)# static e1 to 4 e25 to 26
FastIron-C(config-vlan-ip-proto)# exclude e5 to 8
FastIron-C(config-vlan-ip-proto)# ipx-proto name Blue
FastIron-C(config-vlan-ipx-proto)# no dynamic
FastIron-C(config-vlan-ipx-proto)# static e5 to 8 e25 to 26
FastIron-C(config-vlan-ipx-proto)# exclude e1 to 4
FastIron-C(config-vlan-other-proto)# vlan 3 name IP-Sub_IPX-Net_VLANs
FastIron-C(config-vlan-3)# untag e9 to 16
FastIron-C(config-vlan-3)# tag e25 to 26
FastIron-C(config-vlan-3)# spanning-tree
FastIron-C(config-vlan-3)# ip-sub 1.1.1.0/24 name Green
FastIron-C(config-vlan-ip-subnet)# no dynamic
FastIron-C(config-vlan-ip-subnet)# static e9 to 12 e25 to 26
FastIron-C(config-vlan-ip-subnet)# exclude e13 to 16
FastIron-C(config-vlan-ip-subnet)# ipx-net 1 ethernet_802.3 name Brown
FastIron-C(config-vlan-ipx-network)# no dynamic
FastIron-C(config-vlan-ipx-network)# static e13 to 16 e25 to 26
FastIron-C(config-vlan-ipx-network)# exclude e9 to 12
FastIron-C(config-vlan-ipx-network)# vlan 4 name Purple_ALL-Protocols
FastIron-C(config-vlan-4)# untag e17 to 24
FastIron-C(config-vlan-4)# tag e25 to 26
FastIron-C(config-vlan-4)# spanning-tree
25 - 28 December 2000
