Summary of Contents for Foundry Networks NetIron M2404C
-
Page 1: Installation Guide
Foundry NetIron M2404C and M2404F Metro Access Switches Installation Guide ™ 4980 Great America Parkway Santa Clara, CA 95054 Tel 408.207.1700 www.foundrynetworks.com January 2007... - Page 2 Foundry Networks, BigIron, FastIron, IronView, JetCore, NetIron, ServerIron, TurboIron, IronWare, EdgeIron, IronPoint, the Iron family of marks and the Foundry Logo are trademarks or registered trademarks of Foundry Networks, Inc. in the United States and other countries.
-
Page 3: Safety Considerations
Foundry NetIron M2404C/M2404F Metro Access Switches Safety Considerations This equipment is for use in a restricted access area by qualified personnel only. To avoid electric shock, do not perform any servicing other than those contained in the unpacking instructions. This equipment contains Electrostatic Discharge (ESD) sensitive components. Use ESD protection before servicing or installing components of this system. - Page 4 Foundry NetIron M2404C/M2404F Metro Access Switches WARNING GROUNDING Before connecting the product to the power line, make sure that the protective ground terminal of the device is connected to the safety ground conductor of the mains power cord. The main power supply plug should only be inserted in a socket outlet provided with a connected safety ground.
-
Page 5: Table Of Contents
NTRODUCTION HARDWARE DESCRIPTION ... 4 ... 4 RONT ANEL NetIron M2404C Front Panel Main Components ... 5 NetIron M2404F Front Panel Main Components... 5 ... 6 TATUS NetIron M2404C Port Status LEDs ... 7 NetIron M2404F Port Status LEDs... 7 NetIron M2404F Dual-Mode Port Status LEDs ... - Page 6 Foundry NetIron M2404C/M2404F Metro Access Switches OFTWARE MAGE OWNLOADING A Preparing to Download an Image Using TFTP... 26 Downloading a Device Software Image Using TFTP... 26 Downloading a NI-M2404WebView Image Using TFTP ... 28 OFTWARE PGRADE VIA HOT-SWAPPING A POWER SUPPLY... 30 SPECIFICATIONS ...
-
Page 7: About This Document
Foundry NetIron M2404C/M2404F Metro Access Switches About This Document Who Should Use This Guide The procedures in this manual are for trained and qualified service personnel who are proficient with network switching and routing concepts. Installation, replacement and maintenance of the equipment described in this guide may only be done by trained and qualified service personnel. -
Page 8: Conventions Used In This Document
Foundry NetIron M2404C/M2404F Metro Access Switches Conventions Used in this Document This document uses the following formatting styles and conventions: • CLI syntax and coded examples are represented by mono-space characters and enclosed in rectangular frames. Under this category: Text issued by the device software is represented by... -
Page 9: Overview
Gigabit Ethernet, Enhanced Gigabit Ethernet (MPLS/ VPLS). There are two flavors to the NetIron M2404, the NetIron M2404C and the NetIron M2404F. (1) NetIron M2404C accommodates 24 Fast Ethernet copper ports and 4 Gigabit Ethernet ports;... -
Page 10: Hardware Description
2. Remove the new module from its protective packaging. January 2007 100baseX Ports Figure 3: NetIron M2404F Platform Front Panel 10/100baseTX Ports Figure 4: NetIron M2404C Platform Front Panel © 2007 Foundry Networks, Inc. GigE Ports PSU LEDs Reset Button... -
Page 11: Netiron M2404C Front Panel Main Components
When inserting an SFP tranceiver into ports marked 27 or 28, verify that the SFP is facing upside -down (as shown in figure below). All other SFP ports on the switch face right-side up. Figure 5: Inserting an SFP, upside-down, into the Enhanced GigE Slot... -
Page 12: Unit Leds
Foundry NetIron M2404C/M2404F Metro Access Switches Component GigE Dual-Mode Ports Enhanced GigE Ports Console Management Port Ethernet Management Port RST Button Unit LEDs The following descibes the LEDs on the chassis. Label Function Ethernet management interface status. Platform HW fault. -
Page 13: Port Status Leds
Port 2 The port status LEDs (1 to 24) for NetIron M2404C are situated on the upper row of ports. The LED on the left side of each upper port is associated with that port. The LED on the right side of each upper port is associated with the port underneath that port. -
Page 14: Netiron M2404F Dual-Mode Port Status Leds
Foundry NetIron M2404C/M2404F Metro Access Switches NetIron M2404F Dual-Mode Port Status LEDs Figure 8: Location of NetIron M2404F Dual-Mode Port Status LEDs Dual-mode port status LEDs are associated with dual-mode RJ45/SFP GiGE ports 25 and 26. RJ-45 Indicators RJ45 Dual-Mode Port Status... -
Page 15: Rear Panel - With Ac Power-Supply Units
Foundry NetIron M2404C/M2404F Metro Access Switches Rear Panel – with AC Power-Supply Units Hot-swappable PSU #2 On-off AC-Power switch Panel Main Components Two AC Power supplies Two grounding posts January 2007 Fan apertures Grounding studs inlet Figure 9: Rear Pane l with AC PSUs... -
Page 16: Rear Panel - With Dc Power-Supply Units
Foundry NetIron M2404C/M2404F Metro Access Switches Rear Panel – with DC Power-supply Units Hot-swappable PSU #2 Terminal PWR and block Invert. Con. Panel Main Components Two DC Power supplies Two grounding posts Power Supply Units Power is fed to the platform via two redundant hot-swappable power supply units (PSUs). The... -
Page 17: Blank Covers
Foundry NetIron M2404C/M2404F Metro Access Switches DC power-supply terminals: -48V/3A GND +BAT.RET The DC power supply panel has the following components: Input terminals: -48V/3A +BAT.RET NOTE Neither the +BAT.RET nor the -48VDC is connected to the GND terminal. If required, this can be performed externally by the user. - Page 18 Foundry NetIron M2404C/M2404F Metro Access Switches Figure 13 Blank Filler for Empty Power-Supply Slot January 2007 © 2007 Foundry Networks, Inc.
-
Page 19: Installation And Setup
Foundry NetIron M2404C/M2404F Metro Access Switches Installation and Setup This section provides installation and setup instructions. The platform can be installed in a standard 19-inch rack or as a standalone unit in a desktop configuration. Packing List The shipping package includes the following items: •... -
Page 20: Rack Mounting Specifications
Foundry NetIron M2404C/M2404F Metro Access Switches WARNING Make sure the rack or cabinet housing the device is adequately secured to prevent it from becoming unstable or falling over. Rack Mounting Specifications Width Height Depth Distance between mounting holes 12.7 15.875 January 2007 Basic body: 440 mm (17.4”) -
Page 21: Ethernet Cables
Foundry NetIron M2404C/M2404F Metro Access Switches Ethernet Cables When connecting an RJ-45/RJ-48 port to an end station, workstation or server, use a standard RJ-45/RJ-48 pin-out cable. Console Interface A simple menu-driven interface provides for system initialization and diagnostics. The Console interface is EIA232 VT-100 compatible. -
Page 22: Grounding The Switch
Foundry NetIron M2404C/M2404F Metro Access Switches For each DC power block a set of a minimum 2x18AWG cables shall be used with suitable end terminal legs matching the conductor’s gauge. Use a RED lead to for the positive conductor and a BLACK lead for the negative conductor. -
Page 23: Laser Safety
Mount the lug on the two grounding posts, replace the spring-washers and fasten the bolts. Avoid using excessive torque. Connect the grounding wire to a reliable ground. If the switch is mounted in a rack, use a common ground for all devices on the rack, according to your company’s policy. -
Page 24: Initial Configuration Using The Console
The Configuration command-language interface (CLI) is accessed by using a VT-100 (or compatible terminal) to the console port of the switch. The terminal port parameters are fixed at: 9600 bps, 8 data bits, 1 stop bit, no parity and without flow control. This provides a convenient method for initial setup of the switch. -
Page 25: Saving Configuration In A Text File
Enter configure mode. Type the command: configure terminal. Set the switch IP address: Type the command: ip address <aa.bb.cc.dd/yy>, where <aa.bb.cc.dd> is the IP address assigned to the switch and yy is the number of bits in the netmask (e.g. netmask of 255.255.255.0 would be /24). -
Page 26: Downloading Configuration From Backup Text File
Foundry NetIron M2404C/M2404F Metro Access Switches application java running-config startup-config To write the backup configuration file, type: device-name#copy startup-config <IP address> <filename> <filename> is the file where the configuration file was saved. Downloading Configuration from Backup Text File The configuration file can be easily downloaded, using the copy command. Type: copy tftp://<Server IP address>/<filename>... -
Page 27: Temperature Management Commands
Foundry NetIron M2404C/M2404F Metro Access Switches Temperature Management Commands Viewing the Status: device-name#show temperature CPU Temperature = 28C / 82F device-name#show temperature high-limit CPU Temperature high limit = 20C / 68F Configuring Temperature Management Parameters: device-name#configure terminal device-name(config)#monitor temperature device-name(config monitor temperature C)#limit... -
Page 28: Monitoring The Power Supplies Status
Foundry NetIron M2404C/M2404F Metro Access Switches Monitoring the Power Supplies Status Viewing the status during system boot: BUILT-IN SELF TEST ------------------ CPU Core Test CPU Interface Test Data Buffer Test Power Supply Test On-board Power Test : Passed Fan Test Viewing the status during operation: The Power Supply status is available on the DC and dual-feed AC models only. -
Page 29: Built-In Self Test (Bist)
Foundry NetIron M2404C/M2404F Metro Access Switches Built-In Self Test (BIST) The BIST performs a set of basic hardware and configuration validity tests. Tests in the BIST are sorted into several groups – for example, the tests of the Power Supply units belong to a Power Supply Test group. -
Page 30: Startup Execution Of Bist
In such cases, the switch starts in debug mode (switching disabled and the switch is running with the default configuration). If one of the On-Board Power level checks fails, the switch will not initialize the ports and will start in a special debug mode, as shown below: Press any key to stop auto-boot... - Page 31 Foundry NetIron M2404C/M2404F Metro Access Switches //////////////////////////////////////////////////////////////////// //...// FOUNDRY NETWORKS Switch model SW version //////////////////////////////////////////////////////////////////// User Access Verification Password: device-name> In this case, you can enter into Enable mode as usual, and examine the detailed Self-Test results. For example: #self-test device-name Processing BIST by request...
-
Page 32: Software Download
Ensure that the workstation acting as TFTP server is configured properly. • Ensure that the switch has a route to the TFTP server. The switch and the TFTP server must be in the same subnet if you do not have a router to route traffic between subnets. Use the ping command to check connectivity to the TFTP server. - Page 33 Copy the device software image file to the appropriate TFTP directory on the workstation. Log into the switch through the console port or through a Telnet session. If you log in using Telnet, your Telnet session will disconnect when you reset the switch to run the new software.
-
Page 34: Downloading A Ni-M2404Webview Image Using Tftp
M2404v2.0.bin device-name(boot param)#device local device-name(boot param)#exit Reset the switch using one of the reload commands. Note that, if you are connected to the switch through Telnet, your Telnet session will be disconnected. Select from the following reload commands: 1. -
Page 35: Software Upgrade Via Ethernet Port (Outband)
The switch has an Ethernet port which allows the user to access it for management purposes or software upgrades. This port, labeled ETH, is on the left side of the switch’s front panel and is not one of the switched ports. In order to configure this port for IP, the following commands... -
Page 36: Hot-Swapping A Power Supply
Foundry NetIron M2404C/M2404F Metro Access Switches Hot-swapping a Power Supply The switch has two redundant power supplies, and can be operated when only one power supply is connected and powered on, or with both power supplies active. When both power supplies are active, you can remove or replace one power supply unit without interrupting the operation of the switch. -
Page 37: Specifications
Foundry NetIron M2404C/M2404F Metro Access Switches Specifications Physical Specifications Dimensions Width Height Depth Weight Operating Conditions AC power source Voltage: Frequency: DC power source Voltage: Operating temperature: Short term extended temperature: Humidity: Relative Humidity: Operating Altitude: Storage Temperature: Storage Humidity:... -
Page 38: Management Features
Foundry NetIron M2404C/M2404F Metro Access Switches Environment: Management Features Inband: Integrated SNMP agent Java applet , Telnet and SSH MIBs Supported: MIB II, Bridge MIB, Private MIB ,RMON MIB (Groups 1,2,3,9) Traps/Alarms: SNMP traps to NMS Console Port: For initial configuration via dedicated RJ-45 connector... -
Page 39: Fcc 47 Cfr: 2003 Part 15 Subpart B, Class A
Foundry NetIron M2404C/M2404F Metro Access Switches FCC 47 CFR: 2003 part 15 subpart B, class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 40: Appendix A: Cautions And Warnings
Foundry NetIron M2404C/M2404F Metro Access Switches Appendix A: Cautions and Warnings Caution Statements A caution calls your attention to a possible hazard that can damage equipment. "Vorsicht” weist auf die Gefahr einer möglichen Beschädigung des Gerätes in. Une mise en garde attire votre attention sur un risque possible d'endommagement de l'équipement. - Page 41 Foundry NetIron M2404C/M2404F Metro Access Switches energía retirado no se reemplaza, inserte el relleno PSU en blanco provisto en el slot y asegúrelo al panel con los dos tornillos. CAUTION: Changes or modifications made to this device that are not expressly approved by the party responsible for compliance could void the user’s...
-
Page 42: Warning Statements
Foundry NetIron M2404C/M2404F Metro Access Switches Warning Statements A warning calls your attention to a possible hazard that can cause injury or death. The following are the warnings used in this manual. "Achtung" weist auf eine mögliche Gefährdung hin, die zu Verletzungen oder Tod führen können. - Page 43 Trennen Sie das Gerät vom Netz, bevor Sie die Abdeckung abnehmen. Alle Einstellungs- und Wartungsarbeiten am geöffneten Gerät dürfen nur von Fachleuten durchgeführt werden, die eine Foundry Networks Zertifizierung nachweisen können. Diese Arbeiten dürfen nur an einem von seiner Stromquelle abgetrennten Gerät erfolgen.
- Page 44 Foundry NetIron M2404C/M2404F Metro Access Switches ADVERTENCIA: WARNING: ACHTUNG: AVERTISSEMENT : January 2007 La prise d’alimentation principale doit être insérée uniquement dans une prise ayant un raccordement à la terre. Cette protection ne doit pas être remise en cause par l’utilisation d’une rallonge (câble d’alimentation) ne possédant pas de mise à...
- Page 45 Foundry NetIron M2404C/M2404F Metro Access Switches ADVERTENCIA: WARNING: ACHTUNG: AVERTISSEMENT : ADVERTENCIA: WARNING: ACHTUNG: AVERTISSEMENT : ADVERTENCIA: WARNING: ACHTUNG: January 2007 CABLEADO PARA ENCHUFE DE CORRIENTE NACIONAL Con cada unidad se suministra un cable de alimentación principal según el Código eléctrico nacional (National Electrical Code o NEC) con zócalo IEC moldeado.
- Page 46 Foundry NetIron M2404C/M2404F Metro Access Switches AVERTISSEMENT: ADVERTENCIA: WARNING: ACHTUNG: AVERTISSEMENT: ADVERTENCIA: January 2007 Vérifiez que le chassis ou l’armoire incluant l’unité est bien fixé afin qu’il ne devienne pas instable ou qu’il ne risque pas de tomber. Verifique que el montante o el gabinete que alberga el dispositivo está...
