NEC Xen IPK Features & Specifications Manual page 607

Xen IPK
Station Interface Units
ACD(8)-U( ) ETU
CNF(8)-U( ) ETU
ESI(8)-U( ) ETU
ESIB(8)-U( ) ETU
ESIB(8)-U( ) ETU with
ESIE(8)-U( ) ETU
FMS(2)/(4)-U( ) ETU
OPX(2)-U( ) ETU
SLI(4)-U( ) ETU
SLI(8)-U( ) ETU
VMS(2)/(4)-U( ) ETU
VMS(8)-U( ) ETU
Calculating maximum capacities are based on the system having a minimum of 8 Electronic Station
NOTE 1:
Interface (ESI) ports and 4 Trunk ports.
When 2-port Station Interface ETUs are installed, the system uses 4 ports from its maximum port
NOTE 2:
capacity.
Only one FMS or VMS system can be installed in one Xen IPK system.
NOTE 3:
NOTE 4: In Memory Block 7-2 (Telephone Type Assignment), a maximum of 32 Digital Voice Mail ports are
available.
In Memory Block 7-1 (Card Interface Slot Assignment), the ACD(8)-U( ) ETU is assigned as "VMS 8"
NOTE 5:
and "Digital VM" in Memory Block 7-2 (Telephone Type Assignment).
In Memory Block 7-1 (Card Interface Slot Assignment), the CNF(8)-U( ) ETU is assigned as "SLI 8" and
NOTE 6:
"VM (Yes)" in Memory Block 4-35 (Voice Mail/SLT Selection).
In Memory Block 4-35 (Voice Mail/SLT Selection), a maximum of 16 analogue Voice Mail ports are
NOTE 7:
available.
Features and Specifications Manual
The available
Universal Slots with the Xen IPK system are shown in the following
tables.
Description
8-port ACD System
8-port Conference Unit
8-port Electronic Station Interface
8-port Electronic Station Interface
16-port Electronic Station Interface
2-or 4-port Digital Voice Mail System
2-port Off-Premise Extension Interface
4-port Single Line Interface
8-port Single Line Interface
2-or 4-port Digital Voice Mail System
8-port Digital Voice Mail System
Features and Specifications Manual
interface cards and
Maximum Capacities
Basic Port
Package
1
2
4
4
2
1
6
6
3
1
1
maximum capacities
Notes
Expanded
Port Package
1 Note 1, 4, 6
2 Note 1, 7, 8
15 Note 1
15 Note 1
7 Note 1
1 Note 1~4
22 Note 1, 2
22 Note 1
14 Note 1
1 Note 1~4
1 Note 1, 3, 4
U3 – 599
for
