Keysight Technologies C Series User Manual page 672

Channel Scanner (Option 312)
How to Set Up Channel Scanner
Using the Antenna/Cable Editor
To learn more, refer to
233–Mixed Analyzers)FUTURE."
page
Using Mapping
Channel Scanner mode has indoor and outdoor mapping capability. Refer to
Chapter 16, "Indoor and Outdoor Mapping – Option 352 (Requires Spectrum
Analyzer Mode (Option 233), and GPS Receiver (Option 307))."
Using Resolution Bandwidth Tradeoff (Res BW Tradeoff)
This feature controls the resolution bandwidth for the current measurement.
To use this feature, press BW 2
following:
—
—
—
670
Chapter 9, "SA (Spectrum Analyzer) Mode (Option
165.
High Sensitivity
– Use this setting for greatest accuracy (Res BW = 1500).
Medium – This is the default setting (Res BW = 450).
Speed
– When you want the fastest possible measurement (Res BW = 150).
and to "Using the Antenna/Cable Editor" on
Res BW Tradeoff
> then choose from the
Keysight N9915-90020 User's Guide
