SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)FUTURE
SA Mode Settings
Figure 9-4 FieldFox Antenna Editors – Settings and Values
How to use the Antenna/Cable Editor
1. Press Scale/Amptd >
2. Then
3. Press
4. Then use the
166
Before editing the antenna settings, it is important to know whether
you are using a magnetic H-field (dB S/m) or electric E-field (dB /m)
antenna. When you setup the Antenna Factor Correction table, you
will select one of these two units so that the FieldFox knows how to
convert the measurement data to various Field Strength Amplitude
units.
— Antenna Off to open the antenna editing softkeys
— Cable Off
to open the cable editing softkeys
Edit Antenna or
New then Yes
table and reset header information to default settings.
arrows to select a field.
— To edit header information, press
using the FieldFox labeler.
— Description: Enter a description for the antenna or cable
correction table. This is NOT the filename used to save the
file.
— Antenna Factor
measurement Amplitude units will be available or not, and
how to convert between them. Select None (default
More Corrections then choose:
>
Edit Cable to open the Antenna / Cable Editor.
to clear all data from the existing Antenna or Cable
Edit
Unit: Determines whether Field Strength
Keysight N9915-90020 User's Guide
then modify the selected field
