Keysight Technologies C Series User Manual page 543

Interference Analyzer (SA Mode) – Option 236
Spectrogram and Waterfall Displays
— Resolution (Number of Points). Learn more in
Waterfall Angle
This setting allows you to show more or less detail. More detail provides fewer
(time) records.
— Press Meas Setup 4
— Then
— Then
— Then choose from the following:
Learn how to set Red and Blue Limits in
page
Keysight N9915-90020 User's Guide
Waterfall Settings
Waterfall Angle
Moderate
— Compromise between detail and number of records.
— Steep Least detail with highest number of records.
Gradual
— Most detail with lowest number of records.
— Wide Angle Moderate angle with increased space between records.
539.
"Points " on page
"Set Red and Blue Limits" on
203.
541
